Case IH FARMALL 50A vs LS Tractor MT352PCT/PCTC | Side-by-side comparison

ITC Company

Good things come to those who wait.


PTO Power	45 hp	44.2 hp (33.0 kW)
Alternator	Not Published	12 V, 70 A
Air Cleaner	Not Published	Dry
Engine Type	Diesel, turbocharged & aftercooled (intercooled)	3-Cylinder, liquid-cooled, Diesel, TC, CRDI
Fuel System	Not Published	CRDI
Displacement	134.2 in³ (2,200 cc)	114.7 in³ (1,879 cc)
No. of Cylinders	3	3
Rated Engine Speed	2,600 rpm	2,600 rpm
Cooling System Type	Not Published	Liquid-cooled
Engine Manufacturer	FPT Industrial	LS Mtron
Engine Emissions Constraints	Tier 4 B/Final	Tier 4
Engine Power (Gross vs. Net HP)	53 hp	Gross: 52.0 hp (38.8 kW)

Tractor Weight with Loader	Not Published	PCT: 4,649 lb (2,109 kg); PCTC: 5,160 lb (2,341 kg)
Weight with Cab and Loader	Not Published	5,160 lb (2,341 kg)
Weight with ROPS and Loader	Not Published	4,649 lb (2,109 kg)

Pump Type	Not Published	Gear pump, engine drive
Steering Flow	Not Published	MEC: 15.5 L/min (4.1 gpm); C-HST: 23.5 L/min (6.2 gpm); S-HST: 26.1 L/min (6.9 gpm)
Implement Flow	45 L/min (11.9 gpm)	31.0 L/min (8.2 gpm)
Total Hydraulic Flow	Not Published	MEC: 46.6 L/min (12.3 gpm); C-HST: 54.5 L/min (14.4 gpm); S-HST: 57.1 L/min (15.1 gpm)
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
Overall Hydraulic Pump Flow	Not Published	MEC: 46.6 L/min (12.3 gpm); C-HST: 54.5 L/min (14.4 gpm); S-HST: 57.1 L/min (15.1 gpm)
No. of Optional Remote Valves	2	3 Pair (2 Detent, 1 STD)
No. of Standard Remote Valves	1	2 Pair (1 Detent, 1 STD)

R3 Turf - Rear	Not Published	41X14-20
R3 Turf - Front	Not Published	28X8.50-15
Tire Size & Options	Not Published	R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear	Not Published	17.5L-24
R4 Industrial - Front	Not Published	12-16.5
R1 Agricultural - Rear	Not Published	13.6-24
R1 Agricultural - Front	Not Published	9.5-16

PTO Rear	540 / 540E	540 rpm
PTO Type	Not Published	Independent PTO with wet disk clutch
Lift Control Type	Mechanical Draft Control (MDC) top link sensing	Position & Draft
Hitch Lift Capacity	Not Published	2,755 lb (1,250 kg)
Mid-PTO Availability	Not Published	Optional (2,000 rpm)
Category, 3-Point Hitch	Category 1/2	Category II
Hitch Lift Capacity (at 24”)	2,701 lb (1,225 kg)	2,469 lb (1,120 kg)
Rear 3-Point Hitch Lift Capacity	Not Published	2,755 lb (1,250 kg)

Coolant Capacity	Not Published	2.3 gal (8.7 L)
Crankcase Capacity	Not Published	1.6 gal (5.9 L)
Fuel Tank Capacity	17.2 gal (65 L)	Cabin: 12.4 gal (47 L); ROPS: 10.6 gal (40 L)
Front Axle Fluid Capacity	Not Published	2.2 gal (8.5 L)
Transmission / Hydraulic System Capacity	Not Published	11.4 gal (43 L)

Loader Lift Height	L545: 106 in (2,680 mm); L555: 105 in (2,670 mm)	94.4 in (2,398 mm)
Loader Breakout Force	L545: 3,131 lb (1,420 kg); L555: 3,527 lb (1,600 kg)	4,063 lb (1,843 kg)
Price for Backhoe Option	Not Published	Not Published
Price for Mid-Mount Mower	Not Published	Not Published
Quick Attach Loader System	Compatible with L545 and L555 loaders	LL4106: 2 Lever Skid Steer Coupler (allows for universal skid steer attachments)
Loader Lift Capacity (Full Height)	L545: 2,205 lb (1,000 kg); L555: 2,734 lb (1,240 kg)	2,680 lb (1,216 kg)

Clutch	Dry clutch	Power clutch valve & lever
No. of Speeds	8 forward / 8 reverse	Gear: F16 x R16
Transmission Type	8x8 mechanical shuttle	Synchro shuttle / Powerclutch
Max Travel Speed (Forward)	Not Published	Not Published
Max Travel Speed (Reverse)	Not Published	Not Published
Differential Lock & Limited Slip Options	Mechanical differential lock; limited slip (MFD)	Mechanical differential lock (pedal)

Brakes	Not Published	Wet, Multi-disc
Steering	Not Published	Hydrostatic Power Steering
Frame Type	Not Published	Not Published
Front Axle Type	2WD or MFD with limited slip	Not Published
Drawbar Capacity	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Seat Suspension & Adjustability	Not Published	Not Published

Wheelbase	96.5 in (2,450 mm) (2WD); 97.6 in (2,478 mm) (MFD)	73.2 in (1,859 mm)
Overall Width	Not Published	62.5 in (1,588 mm)
Ground Clearance	Not Published	Not Published
Height to Top of ROPS	75.9 in (1,930 mm)	95 in (2,413 mm)
Height to Top of Cab Model	Not Applicable	90 in (2,286 mm)
Height to Top of ROPS (folded)	Not Applicable	Not Published
Min. Turn Radius without Brakes	Not Published	10.3 ft (3.1 m)
Overall Length with 3-Point Hitch	129.5 in (3,290 mm) (2WD); 134.0 in (3,404 mm) (MFD)	133 in (3,378 mm)

Financing Options	Not Published	0% financing up to 96 months on select models; cash rebate incentive (offers vary)
Base Price with Loader	Not Published	Not Published
Warranty Length & Coverage	Not Published	6-year limited powertrain warranty; 2-year bumper-to-bumper warranty
Base Price with Loader + Cab	Not Published	Not Published

Spec sheet sources	[1] caseih.com [2] cnhi-p-001-delivery.sitecorecontenthub.cloud	[1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com

PTO Power

45 hp

44.2 hp (33.0 kW)

Alternator

Not Published

12 V, 70 A

Air Cleaner

Not Published

Dry

Engine Type

Diesel, turbocharged & aftercooled (intercooled)

3-Cylinder, liquid-cooled, Diesel, TC, CRDI

Fuel System

Not Published

CRDI

Displacement

134.2 in³ (2,200 cc)

114.7 in³ (1,879 cc)

No. of Cylinders

Rated Engine Speed

2,600 rpm

Cooling System Type

Not Published

Liquid-cooled

Engine Manufacturer

FPT Industrial

LS Mtron

Engine Emissions Constraints

Tier 4 B/Final

Tier 4

Engine Power (Gross vs. Net HP)

53 hp

Gross: 52.0 hp (38.8 kW)

Tractor Weight with Loader

Not Published

PCT: 4,649 lb (2,109 kg); PCTC: 5,160 lb (2,341 kg)

Weight with Cab and Loader

Not Published

5,160 lb (2,341 kg)

Weight with ROPS and Loader

Not Published

4,649 lb (2,109 kg)

Pump Type

Not Published

Gear pump, engine drive

Steering Flow

Not Published

MEC: 15.5 L/min (4.1 gpm); C-HST: 23.5 L/min (6.2 gpm); S-HST: 26.1 L/min (6.9 gpm)

Implement Flow

45 L/min (11.9 gpm)

31.0 L/min (8.2 gpm)

Total Hydraulic Flow

Not Published

MEC: 46.6 L/min (12.3 gpm); C-HST: 54.5 L/min (14.4 gpm); S-HST: 57.1 L/min (15.1 gpm)

Hydraulic System Type

Open center

Rear Remote Hydraulic Flow

Not Published

Overall Hydraulic Pump Flow

Not Published

MEC: 46.6 L/min (12.3 gpm); C-HST: 54.5 L/min (14.4 gpm); S-HST: 57.1 L/min (15.1 gpm)

No. of Optional Remote Valves

3 Pair (2 Detent, 1 STD)

No. of Standard Remote Valves

2 Pair (1 Detent, 1 STD)

R3 Turf - Rear

Not Published

41X14-20

R3 Turf - Front

Not Published

28X8.50-15

Tire Size & Options

Not Published

R1 Agricultural, R3 Turf, R4 Industrial

R4 Industrial - Rear

Not Published

17.5L-24

R4 Industrial - Front

Not Published

12-16.5

R1 Agricultural - Rear

Not Published

13.6-24

R1 Agricultural - Front

Not Published

9.5-16

PTO Rear

540 / 540E

540 rpm

PTO Type

Not Published

Independent PTO with wet disk clutch

Lift Control Type

Mechanical Draft Control (MDC) top link sensing

Position & Draft

Hitch Lift Capacity

Not Published

2,755 lb (1,250 kg)

Mid-PTO Availability

Not Published

Optional (2,000 rpm)

Category, 3-Point Hitch

Category 1/2

Category II

Hitch Lift Capacity (at 24”)

2,701 lb (1,225 kg)

2,469 lb (1,120 kg)

Rear 3-Point Hitch Lift Capacity

Not Published

2,755 lb (1,250 kg)

Coolant Capacity

Not Published

2.3 gal (8.7 L)

Crankcase Capacity

Not Published

1.6 gal (5.9 L)

Fuel Tank Capacity

17.2 gal (65 L)

Cabin: 12.4 gal (47 L); ROPS: 10.6 gal (40 L)

Front Axle Fluid Capacity

Not Published

2.2 gal (8.5 L)

Transmission / Hydraulic System Capacity

Not Published

11.4 gal (43 L)

Loader Lift Height

L545: 106 in (2,680 mm); L555: 105 in (2,670 mm)

94.4 in (2,398 mm)

Loader Breakout Force

L545: 3,131 lb (1,420 kg); L555: 3,527 lb (1,600 kg)

4,063 lb (1,843 kg)

Price for Backhoe Option

Not Published

Price for Mid-Mount Mower

Not Published

Quick Attach Loader System

Compatible with L545 and L555 loaders

LL4106: 2 Lever Skid Steer Coupler (allows for universal skid steer attachments)

Loader Lift Capacity (Full Height)

L545: 2,205 lb (1,000 kg); L555: 2,734 lb (1,240 kg)

2,680 lb (1,216 kg)

Clutch

Dry clutch

Power clutch valve & lever

No. of Speeds

8 forward / 8 reverse

Gear: F16 x R16

Transmission Type

8x8 mechanical shuttle

Synchro shuttle / Powerclutch

Max Travel Speed (Forward)

Not Published

Max Travel Speed (Reverse)

Not Published

Differential Lock & Limited Slip Options

Mechanical differential lock; limited slip (MFD)

Mechanical differential lock (pedal)

Brakes

Not Published

Wet, Multi-disc

Steering

Not Published

Hydrostatic Power Steering

Frame Type

Not Published

Front Axle Type

2WD or MFD with limited slip

Not Published

Drawbar Capacity

Not Published

Front Axle Rating

Not Published

Seat Suspension & Adjustability

Not Published

Wheelbase

96.5 in (2,450 mm) (2WD); 97.6 in (2,478 mm) (MFD)

73.2 in (1,859 mm)

Overall Width

Not Published

62.5 in (1,588 mm)

Ground Clearance

Not Published

Height to Top of ROPS

75.9 in (1,930 mm)

95 in (2,413 mm)

Height to Top of Cab Model

Not Applicable

90 in (2,286 mm)

Height to Top of ROPS (folded)

Not Applicable

Not Published

Min. Turn Radius without Brakes

Not Published

10.3 ft (3.1 m)

Overall Length with 3-Point Hitch

129.5 in (3,290 mm) (2WD); 134.0 in (3,404 mm) (MFD)

133 in (3,378 mm)

Financing Options

Not Published

0% financing up to 96 months on select models; cash rebate incentive (offers vary)

Base Price with Loader

Not Published

Warranty Length & Coverage

Not Published

6-year limited powertrain warranty; 2-year bumper-to-bumper warranty

Base Price with Loader + Cab

Not Published

Spec sheet sources

[1] caseih.com [2] cnhi-p-001-delivery.sitecorecontenthub.cloud

[1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com
