Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
CaseIHFARMALL60A
No photo
—
Mahindra2660HSTCAB
Comparison loaded for 2 tractors.
Spec
Case IHFARMALL 60A
Mahindra2660 HST CAB
PTO Power
51 hp
46.3 hp (34.5 kW)
Alternator
Not Published
12 V, 90 A
Air Cleaner
Not Published
Not Published
Engine Type
Diesel, turbocharged & aftercooled (intercooled)
Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine
Fuel System
Not Published
Direct Injection (mCRD fuel-injected)
Displacement
2.2 L
161.7 in³ (2650 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,600 rpm
2300 rpm
Cooling System Type
Not Published
Water-cooled
Engine Manufacturer
FPT Industrial
Mahindra
Engine Emissions Constraints
Tier 4 B/Final (no DEF required)
No DPF (Diesel Particulate Filter)
Engine Power (Gross vs. Net HP)
60 hp (engine)
Gross: 60 hp (44.5 kW)
Tractor Weight with Loader
Not Published
5855 lb (2656 kg)
Weight with Cab and Loader
Not Applicable
5855 lb (2656 kg)
Weight with ROPS and Loader
Not Published
Not Applicable
Pump Type
Not Published
Not Published
Steering Flow
Not Published
18.5 L/min (4.9 gpm)
Implement Flow
45 L/min (11.9 gpm)
44.7 L/min (11.8 gpm)
Total Hydraulic Flow
Not Published
63.2 L/min (16.7 gpm)
Hydraulic System Type
Open center
Open Center
Rear Remote Hydraulic Flow
Rear remotes (standard/optional): 1 / 2
Not Published
Overall Hydraulic Pump Flow
Not Published
63.2 L/min (16.7 gpm)
No. of Optional Remote Valves
2
Not Published
No. of Standard Remote Valves
1
1 Spool
R3 Turf - Rear
Not Published
LSW570-648
R3 Turf - Front
Not Published
LSW305-521
Tire Size & Options
Not Published
R1 Agricultural, R4 Industrial, R3 Turf
R4 Industrial - Rear
Not Published
16.9X24 8PR
R4 Industrial - Front
Not Published
12X16.5 6PR
R1 Agricultural - Rear
Not Published
14.9X24 6PR
R1 Agricultural - Front
Not Published
9.5X16 6PR
PTO Rear
540 rpm (std) / 540E (opt)
540 rpm @ 2300 rpm
PTO Type
Not Published
Independent
Lift Control Type
Mechanical Draft Control (MDC), top link sensing
Position Control
Hitch Lift Capacity
Not Published
Not Published
Mid-PTO Availability
Not Published
Optional
Category, 3-Point Hitch
Category 1/2
CAT I with Telescoping Stabilizers & Flex Links
Hitch Lift Capacity (at 24”)
2,701 lb (1,225 kg) @ 24 in behind pin
3314 lb (1503 kg)
Rear 3-Point Hitch Lift Capacity
2,701 lb (1,225 kg) @ 24 in behind pin
Not Published
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
17.2 gal (65 L)
16 gal (60.6 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
L545: 106 in (2,680 mm); L555: 105 in (2,670 mm)
115.4 in (2931 mm)
Loader Breakout Force
L545: 3,131 lb (1,420 kg); L555: 3,527 lb (1,600 kg)
5225 lb
Price for Backhoe Option
Not Published
Not Applicable
Price for Mid-Mount Mower
Not Published
Not Applicable
Quick Attach Loader System
Compatible loaders: L545, L555
2660CL: Quick-attach adapter included (loader interfaces with compatible attachments via quick-attach system).
Loader Lift Capacity (Full Height)
L545: 2,205 lb (1,000 kg); L555: 2,734 lb (1,240 kg)
