▶ EnginePTO Power 57.6 hp 64 hp Alternator 60 A, 12 V Not Published Air Cleaner Dry type air cleaner with safety element Not Published Engine Type Diesel, turbocharged and aftercooled Diesel, turbocharged Fuel System Electronically controlled, high-pressure common rail Not Published Displacement 179 in³ 207.5 in³ No. of Cylinders 3 4 Rated Engine Speed 2100 rpm 2300 rpm Cooling System Type Liquid-cooled Not Published Engine Manufacturer John Deere PowerTech 3029 EWR FPT Industrial Engine Power (Gross) 74.8 hp @ 100 rpm 74 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Not Published Steering Flow 6.8 gpm Not Published Implement Flow 11.4 gpm 12.5 gpm Total Hydraulic Flow 18.2 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published Overall Hydraulic Pump Flow 18.2 gpm Not Published No. of Optional Remote Valves 2 3 No. of Standard Remote Valves 1 2 ▶ PTO & HitchPTO Rear 540 @ 2083 engine rpm; 540E @ 1588 engine rpm 540 / 540/540E PTO Type Independent PTO: 540 (SyncShuttle); 540/540E (PowrReverser) Not Published Lift Control Type Position and draft control; adjustable rate of drop Mechanical Draft Control (MDC) top link sensing Hitch Lift Capacity 3,968 lb @ hitch points 3,664 lb @ 24 in behind pin Mid-PTO Availability Not Applicable Not Published Category, 3-Point Hitch Category II; convertible to Category I Category 1/2 Hitch Lift Capacity (at 24”) 3,197 lb @ 24 in behind hitch balls 3,664 lb @ 24 in behind pin ▶ Tire OptionsR3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) Not Published R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Not Published Tire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow Not Published R4 Industrial - Rear 4.6 gal-24 8PR R4; 5.2 gal-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 Not Published R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 Not Published R1 Agricultural - Rear 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W Not Published R1 Agricultural - Front 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W Not Published ▶ Fluid CapacityCoolant Capacity Open operator station: 2.85 gal; Cab: 3.08 gal Not Published Crankcase Capacity 9.0 qt (with filter) Not Published Fuel Tank Capacity Open operator station: 15.6 ± 0.44 gal (71 ± 0.5 gal); Cab: 17.59 ± 0.44 gal (80 ± 0.5 gal) 23.8 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Not Published Transmission / Hydraulic System Capacity 8.36 gal (9x3); 9.46 gal (12x12) Not Published ▶ Loader & AttachmentsLoader Lift Height 124 in 105 in Loader Breakout Force 4,354 lb (measured at pivot) 3,527 lb Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) L565 Loader Lift Capacity (Full Height) 3,225 lb (measured at pivot) 2,734 lb ▶ Transmission & DrivetrainClutch Dual clutch, 11 in (PowrReverser) Wet clutch No. of Speeds 9 forward / 3 reverse (SyncShuttle); 12 forward / 12 reverse (PowrReverser) 12F/12R (standard); 8F/8R (optional); creeper option (12x12) Transmission Type SyncShuttle 9F/3R (standard); PowrReverser 12F/12R (optional) 12x12 Power shuttle (wet clutch) (standard); 8x8 Power shuttle (wet clutch) (optional); 12x12 Power shuttle (wet clutch) with creeper (optional) Max Travel Speed (Forward) 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) Not Published Max Travel Speed (Reverse) 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical diff lock; HD 2WD or MFD with limited slip ▶ Chassis, Steering & ControlsBrakes Hydraulically actuated wet disk brakes (self-equalizing and self-adjusting) Not Published Steering Hydrostatic power steering Not Published Frame Type Not Published Not Published Front Axle Type 2WD (standard) or MFWD (optional) HD 2WD or MFD with limited slip Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) Not Published Front Axle Rating Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Not Published Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Not Published ▶ Dimensions & ManeuverabilityWheelbase 80.7 in 86 in (2WD); 84 in (MFD) Overall Width Not Published Not Published Ground Clearance Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of Cab Model Not Published 98 in Height to Top of ROPS (folded) Not Published 77.6 in Min. Turn Radius without Brakes 137.8 in (2WD); 183.1 in (4WD) Not Published Overall Length with 3-Point Hitch 143.3 in 153 in (2WD); 151 in (MFD) ▶ Pricing, Financing & WarrantyFinancing Options 0% APR fixed rate for 60 months Not Published Base Price with Loader Not Published Not Published Warranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Not Published Base Price with Loader + Cab Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit
