Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KiotiDK5020
No photo
—
CaseIHFARMALLCOMPACT50C
Comparison loaded for 2 tractors.
Spec
KiotiDK5020
Case IHFARMALL COMPACT 50C
PTO Power
41.5 hp (31.0 kW)
42.5 hp (Gear); 40 hp (Hydro)
Alternator
Not Published
Not Published
Air Cleaner
Not Published
Not Published
Engine Type
Diesel, 4-cycle, water-cooled engine
Diesel, naturally aspirated
Fuel System
Not Published
Common Rail Direct Injection
Displacement
111.4 in³ (1,826 cc)
1.9 L
No. of Cylinders
3
3
Rated Engine Speed
2,600 rpm
Not Published
Cooling System Type
Water-cooled
Not Published
Engine Manufacturer
KIOTI (Daedong)
Not Published
Engine Emissions Constraints
Not Published
Tier 4 B/Final
Engine Power (Gross vs. Net HP)
Gross: 50.3 hp (37.5 kW)
50 hp
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Gear
Not Published
Steering Flow
18.7 L/min (4.94 gpm)
Not Published
Implement Flow
36.4 L/min (9.62 gpm)
8.2 gpm
Total Hydraulic Flow
55.1 L/min (14.56 gpm)
Not Published
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
55.1 L/min (14.56 gpm)
Not Published
No. of Optional Remote Valves
2 (optional)
Not Published
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
21.5L-16.1
Not Published
R3 Turf - Front
29X12.5-15
Not Published
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
Not Published
R4 Industrial - Rear
14.9-24
Not Published
R4 Industrial - Front
10-16.5
Not Published
R1 Agricultural - Rear
13.6-24
Not Published
R1 Agricultural - Front
8.0-16
Not Published
PTO Rear
540 rpm
540 rpm (standard)
PTO Type
Independent
Independent rear PTO with electro-hydraulic engagement (standard)
Lift Control Type
Position
Mechanical position control
Hitch Lift Capacity
2,998 lb (1,360 kg)
Not Published
Mid-PTO Availability
2,000 rpm
Optional mid-PTO @ 2,000 rpm
Category, 3-Point Hitch
Category I
Not Published
Hitch Lift Capacity (at 24”)
2,716 lb (1,232 kg)
2,756 lb (1,250 kg) @ 24 in behind pin
Rear 3-Point Hitch Lift Capacity
2,998 lb (1,360 kg)
Not Published
Coolant Capacity
0.89 gal (3.4 L) (engine only)
Not Published
Crankcase Capacity
1.95 gal (7.4 L)
Not Published
Fuel Tank Capacity
11.9 gal (45 L)
Not Published
Front Axle Fluid Capacity
1.48 gal (5.6 L)
Not Published
Transmission / Hydraulic System Capacity
11.4 gal (43 L)
Not Published
Loader Lift Height
107.7 in (2,735 mm) (to pivot pin)
112 in (2,852 mm)
Loader Breakout Force
3,895 lb (1,767 kg) (at pivot pins)
3,114 lb (1,412 kg)
Price for Backhoe Option
KB2485: $9,504 MSRP (subframe & bucket sold separately)
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Quick attach (QA) bucket
Compatible with L360A loader
Loader Lift Capacity (Full Height)
2,474 lb (1,122 kg) @ 59.84 in (1,520 mm) pivot pin height
