Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KubotaBX2680
No photo
—
CaseIHFARMALL25SC
Comparison loaded for 2 tractors.
Spec
KubotaBX2680
Case IHFARMALL 25SC
PTO Power
19.5 hp (14.5 kW)
17.2 hp
Alternator
12 V, 40 A
Not Published
Air Cleaner
Sheet net and replaceable treated paper element, spin on oil filter
Not Published
Engine Type
Liquid cooled, 4-cycle, diesel
Diesel, naturally aspirated
Fuel System
Direct injection
Indirect injection
Displacement
61.1 in³ (1001 cc)
77.3 in³ (1.26 L)
No. of Cylinders
3
3
Rated Engine Speed
3200 rpm
3,000 rpm
Cooling System Type
Water with pressurized radiator, reverse air-flow design
Water-cooled
Engine Manufacturer
Kubota
Not Published
Engine Emissions Constraints
Not Published
Tier 4 B/Final
Engine Power (Gross vs. Net HP)
Gross: 24.8 hp (18.5 kW)
24.7 hp
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Open center tandem pump gear type
Not Published
Steering Flow
3.8 L/min (1.0 gpm)
Not Published
Implement Flow
19.7 L/min (5.2 gpm)
4.6 gpm
Total Hydraulic Flow
23.5 L/min (6.2 gpm)
Not Published
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
23.5 L/min (6.2 gpm)
Not Published
No. of Optional Remote Valves
2 (optional; ISO 7241-1 series A or B)
1
No. of Standard Remote Valves
Not Published
0
R3 Turf - Rear
26X12-12
Not Published
R3 Turf - Front
18X8.5-10
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
Not Published
R4 Industrial - Rear
26X12-12
Not Published
R4 Industrial - Front
18X8.5-10
Not Published
R1 Agricultural - Rear
26X12-12
Not Published
R1 Agricultural - Front
18X8.5-10
Not Published
PTO Rear
STD (540 rpm)
540 rpm
PTO Type
Live independent PTO (with hydraulic clutch)
Independent electro-hydraulic engagement; Mid-PTO: standard (2,500 rpm)
Lift Control Type
Not Published
Not Published
Hitch Lift Capacity
Not Published
992 lb
Mid-PTO Availability
STD (2500 rpm)
Standard
Category, 3-Point Hitch
SAE Category I Optional
Category 1
Hitch Lift Capacity (at 24”)
680 lb (310 kg)
728 lb (330 kg) @ 24 in behind ball ends
Rear 3-Point Hitch Lift Capacity
Not Published
992 lb
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
6.6 gal (25 L)
6.6 gal (25 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
71.0 in (1804 mm)
Up to 72 in
Loader Breakout Force
1,286 lbf (bucket pivot pin)
Up to 1,426 lb
Price for Backhoe Option
Not Applicable
Not Published
Price for Mid-Mount Mower
Not Applicable
Not Published
Quick Attach Loader System
Swift-Tach® Loader (LA344S — Two Lever Quick Attach Bucket)
L320S
Loader Lift Capacity (Full Height)
739 lb (335 kg)
Up to 693 lb
Clutch
Dry type single plate - Main clutch 9.45 in.
Wet clutch
No. of Speeds
2 Range (Low-High)
Not Published
Transmission Type
Hydrostatic transmission
2-Range Hydrostatic Synchro Shuttle (wet clutch)
Max Travel Speed (Forward)
8.1 mph (13.0 km/h)
Not Published
Max Travel Speed (Reverse)
6.2 mph (10.0 km/h)
Not Published
Differential Lock & Limited Slip Options
Rear differential lock standard
Mechanical differential lock
Brakes
Mechanical, wet disc type
Not Published
Steering
Integral power steering
Not Published
Frame Type
Not Published
Not Published
Front Axle Type
4WD: Bevel gear front axle, non-adjustable tread spacing
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
