Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
LSMT340HC
—
CaseIHFARMALLCOMPACT40C
Comparison loaded for 2 tractors.
Spec
LS TractorMT340HC
Case IHFarmall Compact 40C
PTO Power
32 hp
34 hp
Alternator
70 A, 12 V
Not Published
Air Cleaner
Dry
Not Published
Engine Type
4-stroke, vertical, water cooling, CRDI
Diesel, naturally aspirated
Fuel System
Delphi, CRDI
Not Published
Displacement
114.7 in³
Not Published
No. of Cylinders
3
Not Published
Rated Engine Speed
2600 rpm
Not Published
Cooling System Type
Water-cooled
Not Published
Engine Manufacturer
LS Mtron
Not Published
Engine Power (Gross)
40 hp
40 hp
Engine Emissions Constraints
Tier 4
Tier 4
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Applicable
Not Published
Pump Type
Gear pump, engine drive
Not Published
Steering Flow
5.5 gpm
Not Published
Implement Flow
7.8 gpm
Not Published
Total Hydraulic Flow
13.3 gpm
Not Published
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
13.3 gpm
Not Published
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
2 Pair
Not Published
PTO Rear
540 rpm
Not Published
PTO Type
Independent PTO with wet disk clutch
Not Published
Lift Control Type
Position & Draft
Not Published
Hitch Lift Capacity
1,808 lbs
Not Published
Mid-PTO Availability
Option (2,000 rpm)
Not Published
Category, 3-Point Hitch
Category I
Not Published
Hitch Lift Capacity (at 24”)
1,433 lbs
Not Published
R3 Turf - Rear
41X14-20
Not Published
R3 Turf - Front
25X8.5-14
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
Not Published
R4 Industrial - Rear
43X16-20
Not Published
R4 Industrial - Front
25X8.5-14
Not Published
R1 Agricultural - Rear
11.2-24
Not Published
R1 Agricultural - Front
7.0-14
Not Published
Coolant Capacity
1.9 gal
Not Published
Crankcase Capacity
1.5 gal
Not Published
Fuel Tank Capacity
12.4 gal
Not Published
Front Axle Fluid Capacity
1.7 gal
Not Published
Transmission / Hydraulic System Capacity
7.9 gal
Not Published
Loader Lift Height
94.4 in
105 in
Loader Breakout Force
3,612 lbs
2,640 lb
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
LL3116: Standard Skid Steer Coupler (skid-steer compatible quick-attach)
L350A
Loader Lift Capacity (Full Height)
2,185 lbs
1,540 lb
Clutch
Not Applicable
Not Published
No. of Speeds
2 Pedal with 3 Range - HST
Not Published
Transmission Type
Hydrostatic Drive
12x12 Mechanical Shuttle or 3-range Hydrostatic
Max Travel Speed (Forward)
Not Published
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Mechanical differential lock (pedal)
Not Published
Brakes
Wet, Multi-disc
Not Published
Steering
Hydrostatic Power Steering
Not Published
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
MFD
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
69.1 in
Not Published
Overall Width
59.3 in
Not Published
Ground Clearance
Not Published
Not Published
Height to Top of ROPS
Not Applicable
Not Published
Height to Top of Cab Model
86.6 in
Not Published
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
Not Published
Not Published
Overall Length with 3-Point Hitch
136.1 in
Not Published
Financing Options
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
