▶ EnginePTO Power 18.5 hp (13.8 kW) 19.2 hp (Mechanical shuttle); 17.1 hp (HST) Alternator 12 V, 50 A Not Published Air Cleaner Dry Not Published Engine Type 3-cylinder, Indirect-injection (swirl chamber), Water-cooled Diesel, naturally aspirated Fuel System Indirect injection (in-line pump) Not Published Displacement 80.4 in³ (1318 cc) 80.4 in³ (1,300 cc) No. of Cylinders 3 3 Rated Engine Speed 2500 rpm 2,500 rpm Cooling System Type Water-cooled Not Published Engine Manufacturer Mitsubishi Not Published Engine Emissions Constraints Tier 4 Tier 4 B/Final Engine Power (Gross vs. Net HP) Gross: 24.7 hp (18.4 kW) 24.6 hp ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Transmission drive pump Not Published Steering Flow 10.0 L/min (2.6 gpm) Not Published Implement Flow 22.5 L/min (5.9 gpm) 29.9 L/min (7.9 gpm) Total Hydraulic Flow 32.5 L/min (8.5 gpm) Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 0 (standard) / 1 (optional) (DIA) Overall Hydraulic Pump Flow 32.5 L/min (8.5 gpm) Not Published No. of Optional Remote Valves 1 pair (2 outlets; optional) 1 No. of Standard Remote Valves Not Published 0 ▶ Tire OptionsR3 Turf - Rear 320/65-16.5 Not Published R3 Turf - Front 23X8.50-12 Not Published Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Not Published R4 Industrial - Rear 305/70-16.5 (6PR) Not Published R4 Industrial - Front 23X8.50-12 (4PR) Not Published R1 Agricultural - Rear 255/75-15.3 Not Published R1 Agricultural - Front 23X10.50-12 Not Published ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Electro-hydraulic rear PTO / mid-PTO Not Published Lift Control Type Position control Not Published Hitch Lift Capacity 1,433 lb (650 kg) 1,433 lb (650 kg) @ 24 in behind pin Mid-PTO Availability Standard (2000 rpm) Optional mid-PTO (2,000 rpm) Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity (at 24”) 1,058 lb (480 kg) 1,433 lb (650 kg) @ 24 in behind pin Rear 3-Point Hitch Lift Capacity 1,433 lb (650 kg) 1,433 lb (650 kg) @ 24 in behind pin ▶ Fluid CapacityCoolant Capacity 1.0 gal (3.8 L) Not Published Crankcase Capacity 1.1 gal (4.2 L) Not Published Fuel Tank Capacity 6.6 gal (25 L) 7.4 gal (28 L) Front Axle Fluid Capacity 0.8 gal (3.0 L) Not Published Transmission / Hydraulic System Capacity 5.3 gal (20 L) Not Published ▶ Loader & AttachmentsLoader Lift Height 85.7 in (2177 mm) 94.3 in (2,395 mm) Loader Breakout Force 1,687 lb 1,926 lb (874 kg) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System LL2102: Quick-attach front end loader L330 Loader Lift Capacity (Full Height) 1,276 lb 1,214 lb (551 kg) ▶ Transmission & DrivetrainClutch Not Applicable Dry clutch No. of Speeds 2 ranges 12F/12R (mechanical shuttle); Hydrostatic (optional) Transmission Type Hydrostatic Drive 12x12 Mechanical shuttle with synchro shift (dry clutch) (standard); Hydrostatic (optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock ▶ Chassis Steering & ControlsBrakes Wet, multi-disc Not Published Steering Hydrostatic power steering Not Published Frame Type Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) Mechanical Front Drive (MFD) Drawbar Capacity Horizontal load: 3,527 lb (1,600 kg); Vertical load: 551 lb (250 kg) pulled / 882 lb (400 kg) pushed Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 59 in (1499 mm) 65.9 in (1,674 mm) Overall Width 44.9 in (1140 mm) Not Published Ground Clearance Not Published Not Published Height to Top of ROPS 84.5 in (2146 mm) 88.2 in (2,241 mm) Height to Top of Cab Model Not Published Not Applicable Height to Top of ROPS (folded) Not Published 68.2 in (1,732 mm) Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 103 in (2616 mm) 117.2 in (2,976 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% financing for up to 96 months on select models; cash rebate incentives may be available (limited time; subject to approved credit) Not Published Base Price with Loader Not Published Not Published Warranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Not Published Base Price with Loader + Cab Not Published Not Published ▶ SourcesSpec sheet sources [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com [1] caseih.com [2] cnhi-p-001-delivery.sitecorecontenthub.cloud [3] caseih.com
