Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
NewHollandT4.80V
No photo
—
CaseIHFARMALL75C
Comparison loaded for 2 tractors.
Spec
New HollandT4.80V
Case IHFARMALL 75C
PTO Power
61 hp (45 kW)
64 hp
Alternator
Not Published
Not Published
Air Cleaner
Not Published
Not Published
Engine Type
4-cylinder diesel
Diesel, turbocharged
Fuel System
Electronic fuel injection
Not Published
Displacement
207 in³ (3400 cc)
3.4 L
No. of Cylinders
4
4
Rated Engine Speed
2300 rpm
2,300 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
FPT Industrial
FPT Industrial
Engine Emissions Constraints
Tier 4B Final
Tier 4 B/Final
Engine Power (Gross vs. Net HP)
ISO TR14396: 75 hp (55 kW)
74 hp
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Open center
Not Published
Steering Flow
36 L/min (9.5 gpm)
Not Published
Implement Flow
64 L/min (16.9 gpm)
12.5 gpm (47.5 L)
Total Hydraulic Flow
64 + 36 L/min (16.9 + 9.5 gpm)
Not Published
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
64 + 36 L/min (16.9 + 9.5 gpm)
Not Published
No. of Optional Remote Valves
Not Published
3
No. of Standard Remote Valves
Not Published
2
R3 Turf - Rear
Not Published
Not Published
R3 Turf - Front
Not Published
Not Published
Tire Size & Options
Not Published
Not Published
R4 Industrial - Rear
Not Published
Not Published
R4 Industrial - Front
Not Published
Not Published
R1 Agricultural - Rear
Not Published
Not Published
R1 Agricultural - Front
Not Published
Not Published
PTO Rear
540 / 540E (Std); 540 / 540E / 1000 (Opt)
540 / 540/540E
PTO Type
Electrohydraulic
Not Published
Lift Control Type
Mechanical Draft Control with Lift-O-Matic (Std); Electronic Draft Control (Opt)
