Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
TYMT474
—
BadBoy5045CAB
Comparison loaded for 2 tractors.
Spec
TYMT474
Bad Boy Tractors5045 Cab
PTO Power
35.9 hp
38.4 hp
Alternator
70 A, 12 V
70 A, 12 V
Air Cleaner
Single dry
Dry element
Engine Type
4-cylinder, naturally aspirated diesel
4-cylinder, water-cooled diesel
Fuel System
IDI
Not Published
Displacement
139.5 in³
139.5 in³
No. of Cylinders
4
4
Rated Engine Speed
2600 rpm
2600 rpm
Cooling System Type
Not Published
Water-cooled
Engine Manufacturer
TYM
Not Published
Engine Power (Gross)
48.3 hp
48 hp
Engine Emissions Constraints
Stage V
DPF / DOC
Tractor Weight with Loader
4,310 lb
Not Published
Weight with Cab and Loader
Not Applicable
4,349 lb (tractor only)
Weight with ROPS and Loader
4,310 lb
Not Applicable
Pump Type
Dual gear pump
Not Published
Steering Flow
4.2 gpm
5.0 gpm
Implement Flow
7.7 gpm
5045CS: 11.4 gpm; 5045CH: 10.7 gpm
Total Hydraulic Flow
11.9 gpm
5045CS: 16.4 gpm; 5045CH: 15.7 gpm
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
11.9 gpm
5045CS: 16.4 gpm; 5045CH: 15.7 gpm
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
1
Not Published
PTO Rear
540 rpm
540 / 540E rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Position
Hitch Lift Capacity
2,689.6 lb
3,306 lb
Mid-PTO Availability
Available (Mid-PTO kit)
Not Published
Category, 3-Point Hitch
Category I
Category 1
Hitch Lift Capacity (at 24”)
1,764 lb
2,425 lb
R3 Turf - Rear
12.5x20
Not Published
R3 Turf - Front
Multi-Trac CS 27x10.5-15 NHS TL 4PR
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural
R4 Industrial - Rear
Xtra Grip 43x16.00-20 NHS TL 6PR
Not Published
R4 Industrial - Front
Trac Chief 10-16.50 NHS TL 6PR
Not Published
R1 Agricultural - Rear
Farm Specialist 12.4-24 NHS TL 6PR
13.6-26
R1 Agricultural - Front
Farm Specialist 8.0-16 NHS TL 6PR
9.5-16
Coolant Capacity
6.9 qt
1.56 gal
Crankcase Capacity
6.8 qt
Not Published
Fuel Tank Capacity
9.0 gal
11.8 gal
Front Axle Fluid Capacity
8.7 qt
1.90 gal
Transmission / Hydraulic System Capacity
8.5 gal
10.04 gal
Loader Lift Height
105.6 in
107.7 in (pivot pin)
Loader Breakout Force
3,198 lb
3,660 lb
Price for Backhoe Option
BY75
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
TX47: Quick attachment (Skid/Euro type)
Yes (SSQA)
Loader Lift Capacity (Full Height)
2,152 lb
2,700 lb
Clutch
Dry single plate
Wet, multi-disc
No. of Speeds
F12 x R12
5045CS: 16F/16R; 5045CH: 4-range
Transmission Type
Mechanical
5045CS: Synchro; 5045CH: HST
Max Travel Speed (Forward)
14.9 mph
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Rear differential lock
Brakes
Wet disc
Not Published
Steering
Hydrostatic
Power steering
Frame Type
Not Published
Compact utility tractor, 4WD
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Deluxe suspension seat
Wheelbase
69.7 in
71.1 in
Overall Width
54.5 in
64.9 in
Ground Clearance
12.8 in
15.5 in
Height to Top of ROPS
94.5 in
Not Applicable
Height to Top of Cab Model
Not Applicable
97.0 in
Height to Top of ROPS (folded)
Not Published
Not Applicable
Min. Turn Radius without Brakes
117.5 in
Not Published
Overall Length with 3-Point Hitch
131 in
127.4 in
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
5045 Cab: from $448/month
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
