Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
YanmarSM475
No photo
—
NewHollandWORKMASTER75
Comparison loaded for 2 tractors.
Spec
YanmarSM475
New HollandWORKMASTER 75
PTO Power
64.1 hp (47.8 kW)
60 hp (44.7 kW)
Alternator
Not Published
Not Published
Air Cleaner
Not Published
Not Published
Engine Type
Not Published
Turbocharged 3-cylinder diesel
Fuel System
Not Published
High-pressure common rail
Displacement
Not Published
179 cu in (2933 cc)
No. of Cylinders
Not Published
3
Rated Engine Speed
2,200 rpm
2,300 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
Deutz
FPT Industrial
Engine Emissions Constraints
Not Published
Tier 4B CEGR + DOC (no DPF; no regeneration)
Engine Power (Gross vs. Net HP)
Gross: 74 hp (55.4 kW)
Gross: 74 hp (55.2 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Not Published
Dual pumps
Steering Flow
22 L/min (5.8 gpm)
29 L/min (7.6 gpm)
Implement Flow
39.1 L/min (10.3 gpm)
48 L/min (12.6 gpm)
Total Hydraulic Flow
61.1 L/min (16.1 gpm)
77 L/min (20.2 gpm)
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
61.1 L/min (16.1 gpm)
77 L/min (20.2 gpm)
No. of Optional Remote Valves
Not Published
1
No. of Standard Remote Valves
2
2
R3 Turf - Rear
Not Published
Not Published
R3 Turf - Front
Not Published
Not Published
Tire Size & Options
Not Published
Not Published
R4 Industrial - Rear
Not Published
Not Published
R4 Industrial - Front
Not Published
Not Published
R1 Agricultural - Rear
Not Published
Not Published
R1 Agricultural - Front
Not Published
Not Published
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Hydraulic wet clutch
Lift Control Type
Not Published
Lift-O-Matic
Hitch Lift Capacity
5,115 lb (2,320 kg)
Not Published
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II
Not Published
Hitch Lift Capacity (at 24”)
3,418 lb (1,550 kg)
3,500 lb (1,588 kg)
Rear 3-Point Hitch Lift Capacity
5,115 lb (2,320 kg)
Not Published
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
23.8 gal (90 L)
Not Published
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
133.8 in (3,398 mm)
550LU: 131.3 in (3335 mm); 555LU: 130.0 in (3302 mm)
Loader Breakout Force
5,485 lb (2,488 kg)
Not Published
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Not Published
550LU, 555LU: 72 in bucket; SSL or Euro-style quick attach
Loader Lift Capacity (Full Height)
3,325 lb (1,508 kg)
550LU: 2,425 lb (1,100 kg); 555LU: 3,153 lb (1,430 kg)
Clutch
Wet multi plate
Not Published
No. of Speeds
Not Published
12F/12R
Transmission Type
Power shuttle
12x12 power shuttle
Max Travel Speed (Forward)
Not Published
25 mph (40 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Rear differential lock (foot pedal engagement)
Not Published
Brakes
Not Published
Not Published
Steering
Not Published
Not Published
Frame Type
Not Published
Not Published
Front Axle Type
Selectable 2WD/4WD engagement
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
6,500 lb (2,948 kg) dynamic capacity
Seat Suspension & Adjustability
Mechanical suspension seat
ROPS: Not Published; CAB: Cloth air-suspension seat
Wheelbase
Not Published
83.6 in (2124 mm)
Overall Width
Not Published
Not Published
Ground Clearance
18.3 in (465 mm)
Not Published
Height to Top of ROPS
Not Published
99.8 in (2535 mm)
Height to Top of Cab Model
Not Published
100.2 in (2545 mm)
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
Not Published
Overall Length with 3-Point Hitch
Not Published
154.1 in (3915 mm)
Financing Options
See Exclusive Offers (offer valid through April 30, 2026; eligibility varies)
Not Published
Base Price with Loader
Not Published
2WD: Not Published; 4WD: $68,146
Warranty Length & Coverage
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours
