▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV80F 3TNM74F Engine Type 3 Cylinder, Water-Cooled, Diesel 3 cylinder, water-cooled diesel, natural aspiration No. of Cylinders 3 3 Displacement 77.3 in³ 60.6 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 24.6 hp 21.5 hp PTO Power 18.8 hp 15.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled, forced circulation Water-cooled Air Cleaner Single element, dry Single dry element Fuel System Indirect injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Single gear pump with flow divider Implement Flow 4.2 gpm 4.17 gpm Steering Flow 2.8 gpm 2.11 gpm Total Hydraulic Flow 7.0 gpm 6.3 gpm Overall Hydraulic Pump Flow 6.95 gpm 6.97 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 5.8 gal 6.6 gal Coolant Capacity 0.95 gal 3.7 qt Crankcase Capacity 0.71 gal 2.1 qt Transmission / Hydraulic System Capacity 3.83 gal 3.6 gal Front Axle Fluid Capacity 0.85 gal 2.6 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2,000 rpm Optional, 2,500 rpm Category, 3-Point Hitch Category I (N) Category I (limited) Hitch Lift Capacity 1,323 lb 1,100 lb Hitch Lift Capacity (at 24”) 1,101 lb 679 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) with mechanical H/L constant-mesh range Hydrostatic (HST) No. of Speeds 2 range (H/L) 2 range Max Travel Speed (Forward) 10.5 mph (H range, Ag tires) 7.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch None (HST) Dry single plate Differential Lock & Limited Slip Options Rear differential lock (bevel gears with diff-lock) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Sub-compact tractor; selectable 4WD Sub-compact tractor Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc, foot operated Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Selectable 4WD Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 44.5 in Wheelbase 57.5 in 53.1 in Ground Clearance 9.4 in 8.3 in Min. Turn Radius without Brakes Not Published 86.6 in Height to Top of ROPS 91.3 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 104 in 94.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,638 lb 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 6-12 16x7.50-9 R1 Agricultural - Rear 9.5-16 24x12.00-12 R3 Turf - Front 20x8-10 16x7.50-8 R3 Turf - Rear 29x12.5-15 26x12.00-12 R4 Industrial - Front 23x8.5-12 18x8.5-10 R4 Industrial - Rear 12-16.5 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach front loader Quick attach front loader Loader Model BBL105 BBL100 Loader Lift Height 75.5 in 78.5 in (at pivot pin) Loader Lift Capacity (Full Height) 992 lb (at pivot pin) 617 lb (at pivot pin) Loader Breakout Force 1,531 lbf 1,253 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours
