▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNV80F S3L2 Engine Type 3 Cylinder, Water-Cooled, Diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 77.3 in³ 80.42 in³ Rated Engine Speed 3000 rpm 2500 rpm Engine Power (Gross) 24.6 hp 24 hp PTO Power 18.8 hp Not Published Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled, forced circulation Not Published Air Cleaner Single element, dry Not Published Fuel System Indirect injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Gear pump Single, open center Implement Flow 4.2 gpm Not Published Steering Flow 2.8 gpm Not Published Total Hydraulic Flow 7.0 gpm 3.98 gpm Overall Hydraulic Pump Flow 6.95 gpm 3.98 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 5.8 gal 7 gal Coolant Capacity 0.95 gal 1.1 gal Crankcase Capacity 0.71 gal 1.11 gal Transmission / Hydraulic System Capacity 3.83 gal 6.6 gal Front Axle Fluid Capacity 0.85 gal 0.71 gal ▶ PTO & HitchPTO Type Independent independent PTO Rear 540 rpm 540 rpm at 2451 engine rpm Mid-PTO Availability Standard, 2,000 rpm Yes, 2100 rpm at 2438 engine rpm Category, 3-Point Hitch Category I (N) Category I (CAT-1N) Hitch Lift Capacity 1,323 lb 1,323 lb Hitch Lift Capacity (at 24”) 1,101 lb Not Published Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) with mechanical H/L constant-mesh range Hydrostatic (HST), 2 range No. of Speeds 2 range (H/L) HST with 2 range speeds Max Travel Speed (Forward) 10.5 mph (H range, Ag tires) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch None (HST) Without clutch (hydrostatic drive) Differential Lock & Limited Slip Options Rear differential lock (bevel gears with diff-lock) Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Sub-compact tractor; selectable 4WD Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc, foot operated Oil immersed brakes, mechanical foot operated Seat Suspension & Adjustability Not Published Standard seat with armrest Front Axle Type Selectable 4WD Four wheel drive (4WD), mechanical engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 47.83 in Wheelbase 57.5 in 61.8 in Ground Clearance 9.4 in 9.44 in (front axle) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 91.3 in 91.53 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 104 in 113.98 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,638 lb 2,513 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Industrial: 23x8.50-12 & 33x15.5-16.5; Turf 1: 23x8.50-12 & 33x15.5-16.5; Turf 2: 25x8.50-14 & 13.6x16; Agri 1: 6x12 & 8.3x20; Agri 2: 7x14 & 8.3x24; Radial Agri: 6.5/80-12 & 280/70R18; Galaxy Pro: 220/55 R12 & 280/70 R16; R14: 25x8.50-14 & 14-17.5 R1 Agricultural - Front 6-12 6x12; 7x14; 6.5/80-12 R1 Agricultural - Rear 9.5-16 8.3x20; 8.3x24; 280/70R18 R3 Turf - Front 20x8-10 23x8.50-12; 25x8.50-14 R3 Turf - Rear 29x12.5-15 33x15.5-16.5; 13.6x16 R4 Industrial - Front 23x8.5-12 23x8.50-12 R4 Industrial - Rear 12-16.5 33x15.5-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach front loader Skid steer quick attach Loader Model BBL105 HLN24 (NSL); HBLN24 (NSL); HB24 (MSL) Loader Lift Height 75.5 in HLN24: 82 in; HBLN24: 85 in; HB24: 85 in Loader Lift Capacity (Full Height) 992 lb (at pivot pin) HLN24: 1,500 lb; HBLN24: 926 lb; HB24: 1,411 lb Loader Breakout Force 1,531 lbf HLN24: 1,565 lb; HBLN24: 1,058 lb; HB24: 1,146 lb ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours 3 year full machine warranty; 7 year powertrain warranty
