▶ EngineEngine Manufacturer TYM Yanmar Engine Model A1100N2 3TNV80F Engine Type 3 cylinder, water-cooled diesel, natural aspiration, swirl chamber 3 Cylinder, Water-Cooled, Diesel No. of Cylinders 3 3 Displacement 71.7 in³ 77.3 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 25 hp 24.6 hp PTO Power 18 hp 18.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled, forced circulation Air Cleaner Dry element Single element, dry Fuel System Indirect injection (swirl chamber) Indirect injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear type pump with primary and secondary pumps Gear pump Implement Flow 4.3 gpm 4.2 gpm Steering Flow 3.1 gpm 2.8 gpm Total Hydraulic Flow 7.4 gpm 7.0 gpm Overall Hydraulic Pump Flow 7.7 gpm 6.95 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 6.08 gal 5.8 gal Coolant Capacity 1.21 gal 0.95 gal Crankcase Capacity 0.79 gal 0.71 gal Transmission / Hydraulic System Capacity 2.90 gal 3.83 gal Front Axle Fluid Capacity 0.79 gal 0.85 gal ▶ PTO & HitchPTO Type Live PTO (6 spline shaft) Independent PTO Rear 540 / 960 rpm 540 rpm Mid-PTO Availability Optional, 2,500 rpm Standard, 2,000 rpm Category, 3-Point Hitch Category I Category I (N) Hitch Lift Capacity 1,433 lb 1,323 lb Hitch Lift Capacity (at 24”) 974 lb 1,101 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) Hydrostatic (HST) with mechanical H/L constant-mesh range No. of Speeds 3 range (L/M/H) 2 range (H/L) Max Travel Speed (Forward) 14.8 mph 10.5 mph (H range, Ag tires) Max Travel Speed (Reverse) 14.8 mph Not Published Clutch Dry, single plate None (HST) Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsFrame Type Steel frame with cast iron axles Sub-compact tractor; selectable 4WD Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc, foot operated Seat Suspension & Adjustability Adjustable seat, flips up and back for rear backhoe operation Not Published Front Axle Type Selectable 4WD Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.8 in 45.8 in Wheelbase 65.7 in 57.5 in Ground Clearance 16.4 in 9.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 91.4 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 110 in 104 in ▶ WeightTractor Weight (Base) 2,106 lb 1,638 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R4 Industrial (25x8.50-14 front / 14x17.5 rear) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-16 6PR 6-12 R1 Agricultural - Rear 11.2-20 9.5-16 R3 Turf - Front Not Published 20x8-10 R3 Turf - Rear Not Published 29x12.5-15 R4 Industrial - Front 25x8.50-14 23x8.5-12 R4 Industrial - Rear 14x17.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach front loader Quick attach front loader Loader Model BBL300 BBL105 Loader Lift Height 86 in 75.5 in Loader Lift Capacity (Full Height) 1,314 lb (at pivot pin) 992 lb (at pivot pin) Loader Breakout Force 1,960 lbf 1,531 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
