▶ EngineEngine Manufacturer Daedong TYM Engine Model 3A165LWH A1700N4-BUTC_4 Engine Type Diesel Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 100 in³ 104.7 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 24.5 hp 35 hp PTO Power 21.8 hp 29.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry type, replaceable Not Published Fuel System Indirect injection (IDI) Not Published Alternator 75 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 6.9 gpm 8.2 gpm Steering Flow 4.5 gpm 4.4 gpm Total Hydraulic Flow 11.4 gpm 12.6 gpm Overall Hydraulic Pump Flow 11.4 gpm 12.6 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (rear hydraulics optional) Not Published No. of Optional Remote Valves 2 pairs Up to 2 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.13 gal Coolant Capacity 3.0 qt 1.32 gal Crankcase Capacity 6.1 qt 1.14 gal Transmission / Hydraulic System Capacity 5.8 gal 9.77 gal Front Axle Fluid Capacity 6.3 qt 1.69 gal ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional: 1976 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2271 lb 3,306.9 lb Hitch Lift Capacity (at 24”) 1631 lb 2,425 lb Lift Control Type Hydraulic Position Control System Position control ▶ Transmission & DrivetrainTransmission Type 3-Range HST Hydrostatic (HST), 3-range No. of Speeds Infinite, 3 range 3 range (HST) Max Travel Speed (Forward) 9.4 mph 18.21 mph Max Travel Speed (Reverse) 6.5 mph 18.21 mph Clutch Not Published None (HST) Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Electro-hydraulic power steering Brakes Wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Adjustable seat (standard) Heated leather seat (cab) Front Axle Type Four-wheel drive (standard) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 1433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.9 in 134.88 in Overall Width 62.4 in 56.3 in Wheelbase 65.7 in 65.7 in Ground Clearance 11.7 in 13.19 in Min. Turn Radius without Brakes 96.5 in (with brake applied) Not Published Height to Top of ROPS 92.2 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 85.9 in ▶ WeightTractor Weight (Base) 2634 lb 3,551 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 ag 7-16 / 11.2-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R1 Agricultural - Front 7-16 7-16 R1 Agricultural - Rear 11.4-24 11.2-24 R3 Turf - Front 27x8.5-15 Not Published R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 25x8.5-14 28x8.50-15 R4 Industrial - Rear 15-19.5 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Standard quick attach mounting system SSQA Loader Model FL7 BBL400 Loader Lift Height 95.1 in 104 in Loader Lift Capacity (Full Height) 1369 lb 2,200 lb Loader Breakout Force 2575 lb 3,660 lb ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (whichever occurs first) on all components; powertrain and engine components 48 months (unlimited hours) for consumer purchasers, 36 months or 2000 hours for commercial purchasers Engine and powertrain 72 months or 2,000 hours; other tractor parts 24 months or 1,000 hours ▶ ITC Company AccessoriesAccessories that fit
