▶ EngineEngine Manufacturer Daedong TYM Engine Model 3A165LWM A1700N6-BUTR_3 Engine Type Diesel Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 100 in³ 104.7 in³ Rated Engine Speed 2400 rpm 2100 rpm Engine Power (Gross) 24.5 hp 24.5 hp PTO Power 22.2 hp 19.1 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry type, replaceable Dry Fuel System Indirect injection (IDI) Not Published Alternator 75 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev) Implement Flow 6.9 gpm 7.5 gpm Steering Flow 4.5 gpm 4 gpm Total Hydraulic Flow 11.4 gpm 11.5 gpm Overall Hydraulic Pump Flow 11.4 gpm 11.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (rear hydraulics optional) Not Published No. of Optional Remote Valves 2 pairs 2 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.13 gal Coolant Capacity 3.0 qt 1.32 gal Crankcase Capacity 6.1 qt 1.14 gal Transmission / Hydraulic System Capacity 5.8 gal Manual: 8.98 gal; HST: 9.77 gal Front Axle Fluid Capacity 6.3 qt Not Published ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm 533 rpm Mid-PTO Availability Optional: 1976 rpm Not Published Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity 2271 lb 3,306.9 lb Hitch Lift Capacity (at 24”) 1631 lb 2,425 lb Lift Control Type Hydraulic Position Control System Position control ▶ Transmission & DrivetrainTransmission Type 9F x 3R Manual Hydrostatic (HST) No. of Speeds 9 forward, 3 reverse 3 range (A/B/C) Max Travel Speed (Forward) 9.2 mph Not Published Max Travel Speed (Reverse) 6 mph Not Published Clutch Not Published None (HST) Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Heavy-duty steel frame with cast iron axles Steering Hydrostatic power steering Fully hydraulic power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Adjustable seat (standard) Not Published Front Axle Type Four-wheel drive (standard) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 1433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.9 in 134.88 in Overall Width 62.4 in 56.7 in Wheelbase 65.7 in 65.7 in Ground Clearance 11.7 in 15 in Min. Turn Radius without Brakes 96.5 in (with brake applied) Not Published Height to Top of ROPS 92.2 in 96.85 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2634 lb 2,969.6 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural (8.0-16 / 12.4-24 standard), R4 Industrial (25x8.50-14 / 15-19.5) R1 Agricultural - Front 7-16 8.0-16 R1 Agricultural - Rear 11.4-24 12.4-24 R3 Turf - Front 27x8.5-15 Not Published R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 25x8.5-14 25x8.50-14 R4 Industrial - Rear 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Standard quick attach mounting system Quick attach front loader Loader Model FL7 BBL400 Loader Lift Height 95.1 in 104 in Loader Lift Capacity (Full Height) 1369 lb 2,200 lb Loader Breakout Force 2575 lb 3,660 lbf ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (whichever occurs first) on all components; powertrain and engine components 48 months (unlimited hours) for consumer purchasers, 36 months or 2000 hours for commercial purchasers Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit
