▶ EngineEngine Manufacturer Daedong Kubota Engine Model 3FT-TL4-U V3307-DI Engine Type Turbocharged diesel 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 111.4 in³ 203 in³ Rated Engine Speed 2750 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 49.6 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published 8 in dry, dual element Fuel System Not Published Direct injection Alternator Not Published ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.6 gpm 11.0 gpm Steering Flow 4.5 gpm 6.1 gpm Total Hydraulic Flow 14.1 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 14.1 gpm 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves None standard; 2 pairs optional 1 No. of Optional Remote Valves 2 pairs 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 11.9 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 11.6 qt Transmission / Hydraulic System Capacity Not Published 59.2 qt Front Axle Fluid Capacity Not Published Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not offered (SST model) Not Published Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 2,716 lb 3,307 lb Lift Control Type Hydraulic position control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 8F x 8R synchro shuttle (SST) Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 8 forward, 8 reverse 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 16.3 mph 17.8 mph Max Travel Speed (Reverse) 15.9 mph 18.0 mph Clutch Not Published Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Multiple wet disc, mechanical Seat Suspension & Adjustability Adjustable seat (standard) Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Not Published 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 70.3 in (with industrial tires) 73.2 in Wheelbase 71.2 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 15.3 in (with industrial tires) 15.4 in Min. Turn Radius without Brakes 103.5 in (with assisted braking) 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 97.4 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (open-station ROPS model) 99.8 in Overall Length 125.5 in (with 3-point hitch) 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 3,745 lb 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader n/a (open-station ROPS model) Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 8-16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 13.6-24 16.9-28 R3 Turf - Front Not Published 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear Not Published 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 (4WD) R4 Industrial - Rear Not Published 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Standard quick attach mounting system LA1153: two-lever quick coupler Loader Model FL9 LA1153 Loader Lift Height 103.0 in (to pivot pin) LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) 1,858 lb (at pivot pin, max height) Not Published Loader Breakout Force 3,938 lb (at pivot point) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
