Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
BobcatCT5555
No photo
—
KiotiDK5520
Comparison loaded for 2 tractors.
Spec
BobcatCT5555
KiotiDK5520
PTO Power
43.1 hp (32.1 kW)
46.4 hp (34.6 kW)
Alternator
Not Published
Not Published
Air Cleaner
Not Published
Not Published
Engine Type
Diesel
Diesel, 4-cycle, water-cooled engine
Fuel System
Not Published
Not Published
Displacement
111.4 in³ (1,826 cc)
111.4 in³ (1,826 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,750 rpm
2,600 rpm
Cooling System Type
Not Published
Water-cooled
Engine Manufacturer
Not Published
KIOTI (Daedong)
Engine Emissions Constraints
Not Published
Not Published
Engine Power (Gross vs. Net HP)
55.0 hp (41.0 kW) (Gross)
Gross: 55.0 hp (41.0 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Applicable
Not Published
Pump Type
Not Published
Gear
Steering Flow
31.1 L/min (8.2 gpm)
18.7 L/min (4.94 gpm)
Implement Flow
36.3 L/min (9.6 gpm)
36.4 L/min (9.62 gpm)
Total Hydraulic Flow
67.6 L/min (17.8 gpm)
55.1 L/min (14.56 gpm)
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
67.6 L/min (17.8 gpm)
55.1 L/min (14.56 gpm)
No. of Optional Remote Valves
2
2 (Optional)
No. of Standard Remote Valves
1
Not Published
R3 Turf - Rear
Not Published
21.5L-16.1
R3 Turf - Front
Not Published
29X12.50-15
Tire Size & Options
Not Published
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
Not Published
14.9-24
R4 Industrial - Front
Not Published
10-16.5
R1 Agricultural - Rear
Not Published
13.6-24
R1 Agricultural - Front
Not Published
8.0-16
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position with Draft Control
Position
Hitch Lift Capacity
3,177 lb (1,441 kg)
2,998 lb (1,360 kg)
Mid-PTO Availability
Optional: 2,103 rpm
Optional
Category, 3-Point Hitch
Category 1
Category II
Hitch Lift Capacity (at 24”)
3,177 lb (1,441 kg)
2,716 lb (1,232 kg)
Rear 3-Point Hitch Lift Capacity
3,177 lb (1,441 kg)
2,998 lb (1,360 kg)
Coolant Capacity
Not Published
0.89 gal (3.4 L) (engine only)
Crankcase Capacity
Not Published
1.95 gal (7.4 L)
Fuel Tank Capacity
14.8 gal (56.0 L)
11.9 gal (45 L)
Front Axle Fluid Capacity
Not Published
1.48 gal (5.6 L)
Transmission / Hydraulic System Capacity
Not Published
11.4 gal (43 L)
Loader Lift Height
Not Published
107.7 in (2,735 mm) (to pivot point)
Loader Breakout Force
Not Published
3,895 lb (1,767 kg) (at pivot pins)
Price for Backhoe Option
Not Published
KB2485: $9,504 MSRP (subframe & bucket sold separately)
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Not Published
Quick attach (QA) bucket
Loader Lift Capacity (Full Height)
2,346 lb (1,064 kg)
2,474 lb (1,122 kg) @ 59.84 in (1,520 mm) pivot pin height
Clutch
Not Applicable
Dry single stage
No. of Speeds
Not Applicable
8F/8R
Transmission Type
Infinite, 3 Range Hydrostatic (Servo control valve with Electric sol.)
Synchro shuttle
Max Travel Speed (Forward)
17.5 mph (28.2 km/hr)
16.71 mph (26.9 km/h)
Max Travel Speed (Reverse)
17.5 mph (28.2 km/hr)
16.28 mph (26.2 km/h)
Differential Lock & Limited Slip Options
Std
Rear differential lock (standard)
Brakes
Wet Multi-Disc
Wet disc type
Steering
Hydrostatic power steering
Hydrostatic Power Steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Mechanical 4WD
Drawbar Capacity
Not Published
1,655 lb (750 kg) (Vertical Load)
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
75.6 in (1,920 mm)
71.3 in (1,810 mm)
Overall Width
74.2 in (1,885 mm)
62.8 in (1,596 mm)
Ground Clearance
13.0 in (330 mm)
14.5 in (368 mm)
Height to Top of ROPS
Not Applicable
96.8 in (2,458 mm)
Height to Top of Cab Model
94.2 in (2,393 mm)
Not Published
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
117.6 in (2,990 mm)
Not Published
Overall Length with 3-Point Hitch
139.6 in (3,547 mm)
124.8 in (3,170 mm)
