▶ EngineEngine Manufacturer Daedong Kubota Engine Model 3FT-TH4-U V3307-DI Engine Type Turbocharged diesel 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 111.4 in³ 203 in³ Rated Engine Speed 2750 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 43.1 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published 8 in dry, dual element Fuel System Not Published Direct injection Alternator Not Published ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.6 gpm 11.0 gpm Steering Flow 8.2 gpm 6.1 gpm Total Hydraulic Flow 17.8 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 17.8 gpm 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 pair 1 No. of Optional Remote Valves 2 pairs (2nd and 3rd pairs optional) 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 14.8 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 11.6 qt Transmission / Hydraulic System Capacity Not Published 59.2 qt Front Axle Fluid Capacity Not Published Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional: 2103 rpm Not Published Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 3,177 lb 3,307 lb Lift Control Type Position with draft control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 3-Range E-HST (electronic hydrostatic) Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds Infinite forward and reverse 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 17.5 mph 17.8 mph Max Travel Speed (Reverse) 17.5 mph 18.0 mph Clutch Not Published Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Multiple wet disc, mechanical Seat Suspension & Adjustability Adjustable seat (standard) Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Four-wheel drive (standard) 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 74.2 in (with industrial tires) 73.2 in Wheelbase 75.6 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 13.0 in (with industrial tires) 15.4 in Min. Turn Radius without Brakes 117.6 in (with assisted braking) 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS Not Applicable 96.9 in Height to Top of ROPS (folded) Not Applicable Not Published Height to Top of Cab Model 94.2 in 99.8 in Overall Length 139.6 in (with 3-point hitch) 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 4,685 lb (operating weight) 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5-16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear Not Published 16.9-28 R3 Turf - Front 29-12.5-15 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear 21.5L-16.1 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 10-16.5 12.5/80-18 (4WD) R4 Industrial - Rear 17.5-24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Front-end loader with standard quick attach mounting system LA1153: two-lever quick coupler Loader Model FL9-5 LA1153 Loader Lift Height 108.6 in (to pivot pin) LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) 2,346 lb Not Published Loader Breakout Force 4,524 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours; powertrain 48 months for consumer use, or 36 months or 2,000 hours for business use Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
