▶ EngineEngine Manufacturer Daedong Daedong Engine Model 4HT-TP4A 4HT-TP4A Engine Type Turbocharged diesel Turbocharged diesel No. of Cylinders 4 4 Displacement 148.6 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 73.1 hp 66.4 hp PTO Power 62.1 hp 57.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System Common rail Common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.0 gpm 11.0 gpm Steering Flow 8.2 gpm 6.9 gpm Total Hydraulic Flow 19.2 gpm 17.9 gpm Overall Hydraulic Pump Flow 19.2 gpm 17.9 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 25.1 gal 22.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/540E rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,898 lb 3,594 lb Lift Control Type Position with draft control Position with draft control ▶ Transmission & DrivetrainTransmission Type 3-range powershuttle with electronic clutch 3-range powershuttle with electronic clutch No. of Speeds 12 forward, 12 reverse 12 forward, 12 reverse Max Travel Speed (Forward) 19.9 mph 19.8 mph Max Travel Speed (Reverse) 19.6 mph 19.5 mph Clutch Electronic clutch Electronic clutch Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering with tilt wheel Power steering with tilt wheel Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Suspension seat, adjustable (standard) Suspension seat, adjustable (standard) Front Axle Type Four-wheel drive (standard) Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 83.5 in 77.2 in Wheelbase 83.9 in 82.7 in Ground Clearance 12.3 in 12.3 in Min. Turn Radius without Brakes 154.0 in 147.0 in Height to Top of ROPS Not Published 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101.1 in Not Published Overall Length 150.0 in 148.8 in ▶ WeightTractor Weight (Base) 5,960 lb (operating weight) 5,440 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Industrial (standard), Agricultural, Multi-Use Industrial (standard), Agricultural, Multi-Use R1 Agricultural - Front 11.2-24 9.5-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 12.5/80-18 R4 Industrial - Rear 18.4-24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Bob-Tach Bob-Tach Loader Model FL10 FL10 Loader Lift Height FL10: 129.0 in (to pivot pin) FL10: 129.0 in (to pivot pin) Loader Lift Capacity (Full Height) FL10: 2,813 lb FL10: 2,614 lb (at pivot pin, max height) Loader Breakout Force FL10: 4,628 lb (at pivot point) FL10: 4,558 lb (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours; powertrain 36 months or 2,000 hours Basic 24 months or 1,500 hours; powertrain 36 months or 2,000 hours
