▶ EngineEngine Manufacturer Daedong LS Mtron Engine Model 4HT-TP4A L4C25-T Engine Type Turbocharged diesel In-line vertical, water cooled 4-cycle diesel, CRDI No. of Cylinders 4 4 Displacement 148.6 in³ 152.9 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 73.1 hp 73 hp PTO Power 62.1 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Not Published Dry Fuel System Common rail Not Published Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear type, engine drive Implement Flow 11.0 gpm 13.2 gpm Steering Flow 8.2 gpm 6.6 gpm Total Hydraulic Flow 19.2 gpm 19.8 gpm Overall Hydraulic Pump Flow 19.2 gpm 19.8 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 3 Pairs (Front), 3 Pairs (Rear) No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 25.1 gal 26.4 gal Coolant Capacity Not Published 2.6 gal Crankcase Capacity Not Published 2.1 gal Transmission / Hydraulic System Capacity Not Published 14.5 gal Front Axle Fluid Capacity Not Published 1.5 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/540E rpm 540 / 750 / 1,000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 6,614 lb Hitch Lift Capacity (at 24”) 3,898 lb 4,718 lb Lift Control Type Position with draft control Position & Draft ▶ Transmission & DrivetrainTransmission Type 3-range powershuttle with electronic clutch MT573C: Synchro Shuttle; MT573CPS: Power Shuttle No. of Speeds 12 forward, 12 reverse F20 x R20 Max Travel Speed (Forward) 19.9 mph 19.4 mph Max Travel Speed (Reverse) 19.6 mph Not Published Clutch Electronic clutch MT573C: Dry single clutch; MT573CPS: Wet clutch disks Differential Lock & Limited Slip Options Not Published Electro-hydraulic differential lock (EHD) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering with tilt wheel Hydrostatic Brakes Wet multi-disc Not Published Seat Suspension & Adjustability Suspension seat, adjustable (standard) Air suspension seat (10° swivel) Front Axle Type Four-wheel drive (standard) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 83.5 in 77.5 in Wheelbase 83.9 in 84.6 in Ground Clearance 12.3 in Not Published Min. Turn Radius without Brakes 154.0 in 13.0 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101.1 in 104.4 in Overall Length 150.0 in 150 in (frame to link) ▶ WeightTractor Weight (Base) 5,960 lb (operating weight) MT573C: 6,620 lb; MT573CPS: 6,669 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published MT573C: 7,852 lb (6,620 + 1,232, computed); MT573CPS: 7,901 lb (6,669 + 1,232, computed) ▶ Tire OptionsTire Size & Options Industrial (standard), Agricultural, Multi-Use Ag 11.2-24 / 16.9-30; R14 W320/85R24 122D / W460/85R30 145D R1 Agricultural - Front 11.2-24 11.2-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 18.4-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Bob-Tach LL6100: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin Loader Model FL10 LL6100 Loader Lift Height FL10: 129.0 in (to pivot pin) LL6100: 126.5 in Loader Lift Capacity (Full Height) FL10: 2,813 lb LL6100: 3,626 lb (at pivot pin) Loader Breakout Force FL10: 4,628 lb (at pivot point) LL6100: 6,644 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours; powertrain 36 months or 2,000 hours Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours
