▶ EngineEngine Manufacturer FPT AGCO Power Engine Model Not Published 33 AWIC Engine Type 4-cylinder diesel 3-cylinder, intercooled turbocharged diesel No. of Cylinders 4 3 Displacement 207 in³ 201 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 99 hp 100 hp PTO Power 85 hp 87 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Dual element (primary and secondary) Fuel System High-pressure common rail electronic direct injection High-pressure common rail direct fuel injection Alternator Not Published 80 A ▶ HydraulicsPump Type Not Published Two-stage pump Implement Flow 16.9 gpm Not Published Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) Not Published Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 17.2 gpm No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 3 (3rd through Parts) 1 ▶ Fluid CapacityFuel Tank Capacity 42.3 gal 33 gal Coolant Capacity Not Published 4.2 gal Crankcase Capacity Not Published 3.3 gal Transmission / Hydraulic System Capacity Not Published Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity Not Published Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Independent Independent, electrohydraulic engagement PTO Rear Not Published 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II with flex link ends Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,339 lb (5,620 lb with auxiliary lift ram) 4,850 lb Lift Control Type Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab) Not Published ▶ Transmission & DrivetrainTransmission Type Not Published 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds 12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional) 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch (power shuttle and Hi-Lo) Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Wet disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Air suspension seat with 15-degree swivel (optional); instructional seat (optional) Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Front Axle Type HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo) Heavy-duty 2WD or 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 160 in (MFD cab) Not Published Overall Width 76 in (across standard fenders) 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 90 in (MFD) 88.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 106 in (18.4R34 rear tires) Not Published Height to Top of ROPS (folded) 82.9 in (18.4R34 rear tires) Not Published Height to Top of Cab Model 102 in Not Published ▶ WeightTractor Weight (Base) Not Published 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire 2WD: 9.5L-15 front, 420/85R34 rear; 4WD: 340/85R24 front, 420/85R34 rear R1 Agricultural - Front 7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD) 2WD: 9.5L-15; 4WD: 340/85R24 R1 Agricultural - Rear 18.4R34 (reference tire) 420/85R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published 931X and 936X: universal skid steer type quick release Loader Model L620; L630 FL.3522, FL.3615, 931X, 936X Loader Lift Height L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL) FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) L620: 2,478 lb (NSL) / 3,179 lb (MSL); L630: 2,632 lb (NSL) / 3,428 lb (MSL) (at 31.5 in forward of pivot pin) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
