▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published Not Published Engine Type 4-cylinder diesel, electronic high-pressure common rail 4-cylinder diesel No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 105 hp 99 hp PTO Power 91 hp 85 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Electronic high-pressure common rail High-pressure common rail electronic direct injection Alternator 120 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 17.2 gpm (22.2 gpm optional) 16.9 gpm Steering Flow 10 gpm (11.4 gpm optional) 9.7 gpm Total Hydraulic Flow 27.2 gpm (17.2 + 10, computed) 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow 27.2 gpm (17.2 + 10, computed) 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 3 3 (3rd through Parts) ▶ Fluid CapacityFuel Tank Capacity 37 gal 42.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear Not Published Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II with flex link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 6,393 lb 4,339 lb (5,620 lb with auxiliary lift ram) Lift Control Type Electronic draft control (EDC) with rear fender switch Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab) ▶ Transmission & DrivetrainTransmission Type Not Published Not Published No. of Speeds 12F/12R (20F/20R or 24F/24R optional) 12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet disc, electro-hydraulic power shuttle Wet clutch (power shuttle and Hi-Lo) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Heated air suspension seat with 15-degree swivel (optional) Air suspension seat with 15-degree swivel (optional); instructional seat (optional) Front Axle Type MFD (four-wheel drive) HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 164 in (16.9R-34 rear tires) 160 in (MFD cab) Overall Width 75 in (minimum) 76 in (across standard fenders) Wheelbase 92.5 in 90 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 106 in (18.4R34 rear tires) Height to Top of ROPS (folded) Not Published 82.9 in (18.4R34 rear tires) Height to Top of Cab Model 103 in (16.9R-34 rear tires) 102 in ▶ WeightTractor Weight (Base) 9,370 lb (cab, MFD, 16.9R-34 rear tires) Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural; 16.9R-34 rear reference tire; 38 in rear tires available R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire R1 Agricultural - Front 14.9R24 7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD) R1 Agricultural - Rear Not Published 18.4R34 (reference tire) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick-Latch loader mounting with Quick-Attach faceplate Not Published Loader Model L735 (NSL or MSL); L745 (NSL or MSL) L620; L630 Loader Lift Height L735: 135 in (11 ft 3 in); L745: 146.75 in (12 ft 2.75 in) L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL) Loader Lift Capacity (Full Height) L735: 2,844 lb (NSL) / 2,954 lb (MSL); L745: 3,616 lb (NSL) / 3,814 lb (MSL) (at 31.5 in forward of pivot pin, max height) L620: 2,478 lb (NSL) / 3,179 lb (MSL); L630: 2,632 lb (NSL) / 3,428 lb (MSL) (at 31.5 in forward of pivot pin) Loader Breakout Force L735: 2,976 lb (NSL) / 3,285 lb (MSL); L745: 3,858 lb (NSL) / 4,254 lb (MSL) (boom breakout at 31.5 in) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
