▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published F5G Engine Type 4-cylinder diesel, electronic high-pressure common rail Dual Command: 4-cylinder diesel; Electro Command: 4-cylinder turbocharged diesel, high-pressure common rail, air-to-air intercooled No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 105 hp 107 hp PTO Power 91 hp 93 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Electronic high-pressure common rail Electro Command: high-pressure common rail with electronic fuel delivery control Alternator 120 A 120 A ▶ HydraulicsPump Type Not Published Fixed displacement, tandem pumps (implement and steering) Implement Flow 17.2 gpm (22.2 gpm optional) Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Steering Flow 10 gpm (11.4 gpm optional) Dual Command: 9.7 gpm; Electro Command: 11.4 gpm Total Hydraulic Flow 27.2 gpm (17.2 + 10, computed) Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow 27.2 gpm (17.2 + 10, computed) Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Dual Command: 2 or 3; Electro Command: 2 No. of Optional Remote Valves 3 Electro Command: 3 (plus 2 mid-mount) ▶ Fluid CapacityFuel Tank Capacity 37 gal Electro Command: 43.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent (hydraulic wet disc clutch) PTO Rear Not Published Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Dual Command: 5,620 lb (7,351 lb with optional ram); Electro Command: 8,084 lb Hitch Lift Capacity (at 24”) 6,393 lb Dual Command: 5,620 lb (7,351 lb with optional ram) Lift Control Type Electronic draft control (EDC) with rear fender switch Not Published ▶ Transmission & DrivetrainTransmission Type Not Published Dual Command: 24x24 Dual Command Hi-Lo with power shuttle (standard); Electro Command: 16x16 Electro Command semi-powershift (AutoShift or 32x32 creeper optional) No. of Speeds 12F/12R (20F/20R or 24F/24R optional) Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet disc, electro-hydraulic power shuttle Not Published Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock; TerraLock automatic 4WD and differential lock engagement optional on Electro Command ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Heated air suspension seat with 15-degree swivel (optional) Not Published Front Axle Type MFD (four-wheel drive) 4WD front axle, class 1.5 HD (TerraGlide suspended 4WD front axle optional on Electro Command) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 164 in (16.9R-34 rear tires) Dual Command: 160.9 in; Electro Command: 165 in Overall Width 75 in (minimum) Dual Command: 75.7 in Wheelbase 92.5 in Dual Command: 89.9 in; Electro Command: 93.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Dual Command: 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103 in (16.9R-34 rear tires) Dual Command: 102.1 in; Electro Command: 107 in ▶ WeightTractor Weight (Base) 9,370 lb (cab, MFD, 16.9R-34 rear tires) Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (Cab): 10,031 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural; 16.9R-34 rear reference tire; 38 in rear tires available Not Published R1 Agricultural - Front 14.9R24 14.9R24 R1 Agricultural - Rear Not Published 18.4R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick-Latch loader mounting with Quick-Attach faceplate Skid-steer style or Euro (European) style tool carrier Loader Model L735 (NSL or MSL); L745 (NSL or MSL) 825TL; 835TL (each NSL or MSL); 810LA (NSL); 815LA (MSL) Loader Lift Height L735: 135 in (11 ft 3 in); L745: 146.75 in (12 ft 2.75 in) 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) Loader Lift Capacity (Full Height) L735: 2,844 lb (NSL) / 2,954 lb (MSL); L745: 3,616 lb (NSL) / 3,814 lb (MSL) (at 31.5 in forward of pivot pin, max height) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) Loader Breakout Force L735: 2,976 lb (NSL) / 3,285 lb (MSL); L745: 3,858 lb (NSL) / 4,254 lb (MSL) (boom breakout at 31.5 in) 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
