▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published Not Published Engine Type 4-cylinder diesel 4-cylinder diesel, electronic high-pressure common rail No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 117 hp 105 hp PTO Power 100 hp 91 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System High-pressure common rail electronic direct injection Electronic high-pressure common rail Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 16.9 gpm 17.2 gpm (22.2 gpm optional) Steering Flow 9.7 gpm 10 gpm (11.4 gpm optional) Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) 27.2 gpm (17.2 + 10, computed) Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) 27.2 gpm (17.2 + 10, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 3 (3rd through Parts) 3 ▶ Fluid CapacityFuel Tank Capacity 42.3 gal 37 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear Not Published Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II with flex link ends Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,339 lb (5,620 lb with auxiliary lift ram) 6,393 lb Lift Control Type Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab) Electronic draft control (EDC) with rear fender switch ▶ Transmission & DrivetrainTransmission Type Not Published Not Published No. of Speeds 12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional) 12F/12R (20F/20R or 24F/24R optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch (power shuttle and Hi-Lo) Wet disc, electro-hydraulic power shuttle Differential Lock & Limited Slip Options Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Air suspension seat with 15-degree swivel (optional); instructional seat (optional) Heated air suspension seat with 15-degree swivel (optional) Front Axle Type HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo) MFD (four-wheel drive) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 160 in (MFD cab) 164 in (16.9R-34 rear tires) Overall Width 76 in (across standard fenders) 75 in (minimum) Wheelbase 90 in (MFD) 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 106 in (18.4R34 rear tires) Not Published Height to Top of ROPS (folded) 82.9 in (18.4R34 rear tires) Not Published Height to Top of Cab Model 102 in 103 in (16.9R-34 rear tires) ▶ WeightTractor Weight (Base) Not Published 9,370 lb (cab, MFD, 16.9R-34 rear tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire R1 agricultural; 16.9R-34 rear reference tire; 38 in rear tires available R1 Agricultural - Front 7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD) 14.9R24 R1 Agricultural - Rear 18.4R34 (reference tire) Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-Latch loader mounting with Quick-Attach faceplate Loader Model L620; L630 L735 (NSL or MSL); L745 (NSL or MSL) Loader Lift Height L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL) L735: 135 in (11 ft 3 in); L745: 146.75 in (12 ft 2.75 in) Loader Lift Capacity (Full Height) L620: 2,478 lb (NSL) / 3,179 lb (MSL); L630: 2,632 lb (NSL) / 3,428 lb (MSL) (at 31.5 in forward of pivot pin) L735: 2,844 lb (NSL) / 2,954 lb (MSL); L745: 3,616 lb (NSL) / 3,814 lb (MSL) (at 31.5 in forward of pivot pin, max height) Loader Breakout Force Not Published L735: 2,976 lb (NSL) / 3,285 lb (MSL); L745: 3,858 lb (NSL) / 4,254 lb (MSL) (boom breakout at 31.5 in) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
