▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published Not Published Engine Type Turbocharged 6-cylinder diesel, 12 valves 4-cylinder diesel No. of Cylinders 6 4 Displacement 411 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 125 hp 99 hp PTO Power 105 hp 85 hp Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Mechanical injection High-pressure common rail electronic direct injection Alternator 120 A Not Published ▶ HydraulicsPump Type Fixed displacement pump Not Published Implement Flow 22 gpm 16.9 gpm Steering Flow 9 gpm 9.7 gpm Total Hydraulic Flow 31 gpm 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow 31 gpm 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 4 3 (3rd through Parts) ▶ Fluid CapacityFuel Tank Capacity 62 gal 42.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity 14.8 qt Not Published Transmission / Hydraulic System Capacity 65.5 qt Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/1000 (two individual shafts) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II with flex link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 7,200 lb 4,339 lb (5,620 lb with auxiliary lift ram) Lift Control Type Not Published Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab) ▶ Transmission & DrivetrainTransmission Type Not Published Not Published No. of Speeds 8F/8R (16F/8R optional) 12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional) Max Travel Speed (Forward) 18.4 mph Not Published Max Travel Speed (Reverse) 19.0 mph Not Published Clutch Not Published Wet clutch (power shuttle and Hi-Lo) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Mechanical seat (standard); air suspension seat (optional) Air suspension seat with 15-degree swivel (optional); instructional seat (optional) Front Axle Type Not Published HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 160 in (MFD cab) Overall Width Not Published 76 in (across standard fenders) Wheelbase 105 in (2WD); 104 in (MFD) 90 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 106 in (18.4R34 rear tires) Height to Top of ROPS (folded) Not Published 82.9 in (18.4R34 rear tires) Height to Top of Cab Model Not Published 102 in ▶ WeightTractor Weight (Base) 9,061 lb (2WD ROPS); 9,700 lb (MFD ROPS); 9,766 lb (2WD cab); 10,406 lb (MFD cab) Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire R1 Agricultural - Front Not Published 7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD) R1 Agricultural - Rear 18.4-34 18.4R34 (reference tire) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Lock & Go automatic quick coupling loader mount with Multi-Coupler hydraulic connection Not Published Loader Model L755 L620; L630 Loader Lift Height Not Published L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL) Loader Lift Capacity (Full Height) Not Published L620: 2,478 lb (NSL) / 3,179 lb (MSL); L630: 2,632 lb (NSL) / 3,428 lb (MSL) (at 31.5 in forward of pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
