▶ EngineEngine Manufacturer FPT John Deere Engine Model Not Published PowerTech 4045 EWL Engine Type Turbocharged 6-cylinder diesel, 12 valves Diesel, turbocharged with intercooler, 4-valve HPCR No. of Cylinders 6 4 Displacement 411 in³ 276 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 125 hp 130 hp PTO Power 105 hp 115 hp Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Dry type air cleaner with safety (secondary) element Fuel System Mechanical injection High Pressure Common Rail (HPCR) electronic fuel injection, 4-valve Alternator 120 A 120 A, 12 V ▶ HydraulicsPump Type Fixed displacement pump Tandem gear pump Implement Flow 22 gpm 18.4 gpm Steering Flow 9 gpm 6.3 gpm Total Hydraulic Flow 31 gpm 25.6 gpm Overall Hydraulic Pump Flow 31 gpm 25.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 (rear); 2 (mid) No. of Optional Remote Valves 4 Up to 3 total (rear); up to 3 total (mid) ▶ Fluid CapacityFuel Tank Capacity 62 gal 42.4 gal (Standard Cab) Coolant Capacity Not Published Not Published Crankcase Capacity 14.8 qt Not Published Transmission / Hydraulic System Capacity 65.5 qt Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic clutch PTO Rear 540/1000 (two individual shafts) 540 rpm standard; 540/1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (convertible to I) Hitch Lift Capacity Not Published 6,975 lb standard; 7,868 lb optional Hitch Lift Capacity (at 24”) 7,200 lb 6,975 lb standard; 7,868 lb optional Lift Control Type Not Published Electrohydraulic ▶ Transmission & DrivetrainTransmission Type Not Published PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) No. of Speeds 8F/8R (16F/8R optional) 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) 18.4 mph 24.9 mph; PowrQuad PLUS 16F/16R (standard) or Powr8 32F/16R (optional) Max Travel Speed (Reverse) 19.0 mph Not Published Clutch Not Published Electro-hydraulic Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame design Steering Power steering Power steering Brakes Wet disc Hydraulic wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Mechanical seat (standard); air suspension seat (optional) Mechanical suspension seat standard; air suspension seat optional; premium air suspension seat (heated, low-frequency) optional Front Axle Type Not Published MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 3,197 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published Not Published Overall Width Not Published Not Published Wheelbase 105 in (2WD); 104 in (MFD) 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 9,061 lb (2WD ROPS); 9,700 lb (MFD ROPS); 9,766 lb (2WD cab); 10,406 lb (MFD cab) 9,185 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural R1 Agricultural - Front Not Published 12.4R24 R1 Agricultural - Rear 18.4-34 18.4R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 in, 12PR R4 Bias R4 Industrial - Rear Not Published 19.5L-24 in, 10PR R4 Bias ▶ Loader & AttachmentsQuick Attach Loader System Lock & Go automatic quick coupling loader mount with Multi-Coupler hydraulic connection Not Published Loader Model L755 520M (4WD only); 540M; 540R; 600M Loader Lift Height Not Published 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in, MSL 148-153 in Loader Lift Capacity (Full Height) Not Published 520M (4WD): NSL 3,334.9-3,611.6 lb, MSL 2,460.1-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117.3-3,309.1 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb, MSL 3,891-4,085 lb Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published 24 Months or 2000 Hours, Whichever Comes First (whole-machine, standard Agricultural Equipment tractor term)
