▶ EngineEngine Manufacturer FPT Deutz Engine Model Not Published TCD3.6L4 Engine Type Turbocharged 6-cylinder diesel, 12 valves Water-cooled, 4-cylinder diesel engine No. of Cylinders 6 4 Displacement 411 in³ 221 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 125 hp 127 hp PTO Power 105 hp 116.7 hp Engine Emissions Constraints Tier 3 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dual dry Fuel System Mechanical injection CRDI Alternator 120 A 120 A, 12 V ▶ HydraulicsPump Type Fixed displacement pump Dual gear pump Implement Flow 22 gpm 20.1 gpm Steering Flow 9 gpm 9.1 gpm Total Hydraulic Flow 31 gpm 29.2 gpm Overall Hydraulic Pump Flow 31 gpm 29.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 6 No. of Optional Remote Valves 4 Not Published ▶ Fluid CapacityFuel Tank Capacity 62 gal 50.2 gal Coolant Capacity Not Published 19.1 qt Crankcase Capacity 14.8 qt 8.5 qt Transmission / Hydraulic System Capacity 65.5 qt 26.9 gal Front Axle Fluid Capacity Not Published 6.3 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/1000 (two individual shafts) 540/540E/1000 rpm (Reversible shaft) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 8,261 lb Hitch Lift Capacity (at 24”) 7,200 lb 8,014 lb Lift Control Type Not Published Position/Draft ▶ Transmission & DrivetrainTransmission Type Not Published Power shuttle & 6-speed shift APS No. of Speeds 8F/8R (16F/8R optional) F36 x R36 w/Creep Max Travel Speed (Forward) 18.4 mph 23 mph Max Travel Speed (Reverse) 19.0 mph Not Published Clutch Not Published Wet Multi Plate Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet disc Wet, Multi disc Seat Suspension & Adjustability Mechanical seat (standard); air suspension seat (optional) Air-ride full suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 92.9 in Wheelbase 105 in (2WD); 104 in (MFD) 102 in Ground Clearance Not Published 16.1 in Min. Turn Radius without Brakes Not Published 186.6 in (left); 189 in (right) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 115.7 in Overall Length Not Published 176.8 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 9,061 lb (2WD ROPS); 9,700 lb (MFD ROPS); 9,766 lb (2WD cab); 10,406 lb (MFD cab) 10,020 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published 380/85 R28 R1 Agricultural - Rear 18.4-34 460/85 R38 (18.4R38) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Automatic quick-coupling loader mount with combined hydraulic connection Not Published Loader Model L755 TL130SL Loader Lift Height Not Published TL130SL: 162 in Loader Lift Capacity (Full Height) Not Published TL130SL: 5,415 lb (at pivot pin) Loader Breakout Force Not Published TL130SL: 6,618 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months
