▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model Not Published 3TNV80F Engine Type 3-cylinder, turbocharged & aftercooled, Tier 4 B/Final 3 Cylinder, Water-Cooled, Diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.6 hp PTO Power 19.2 hp 18.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled, forced circulation Air Cleaner Not Published Single element, dry Fuel System Not Published Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump Implement Flow 7.9 gpm 4.2 gpm Steering Flow Not Published 2.8 gpm Total Hydraulic Flow Not Published 7.0 gpm Overall Hydraulic Pump Flow Not Published 6.95 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 5.8 gal Coolant Capacity Not Published 0.95 gal Crankcase Capacity Not Published 0.71 gal Transmission / Hydraulic System Capacity Not Published 3.83 gal Front Axle Fluid Capacity Not Published 0.85 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2,000 rpm Standard, 2,000 rpm Category, 3-Point Hitch Category I Category I (N) Hitch Lift Capacity Not Published 1,323 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,101 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle with synchro shift (dry clutch) (standard) Hydrostatic (HST) with mechanical H/L constant-mesh range No. of Speeds 12 forward, 12 reverse 2 range (H/L) Max Travel Speed (Forward) Not Published 10.5 mph (H range, Ag tires) Max Travel Speed (Reverse) Not Published Not Published Clutch Dry clutch None (HST) Differential Lock & Limited Slip Options Mechanical differential lock Rear differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsFrame Type Not Published Sub-compact tractor; selectable 4WD Steering Power steering Hydrostatic power steering Brakes Not Published Wet disc, foot operated Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical Front Drive (MFD) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 45.8 in Wheelbase 65.9 in 57.5 in Ground Clearance Not Published 9.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 88.2 in 91.3 in Height to Top of ROPS (folded) 68.2 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 117.2 in 104 in ▶ WeightTractor Weight (Base) 2,469 lb 1,638 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 6-12 R1 Agricultural - Rear Not Published 9.5-16 R3 Turf - Front Not Published 20x8-10 R3 Turf - Rear Not Published 29x12.5-15 R4 Industrial - Front Not Published 23x8.5-12 R4 Industrial - Rear Not Published 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach front loader Loader Model L330 BBL105 Loader Lift Height 94.3 in 75.5 in Loader Lift Capacity (Full Height) 1,214 lb 992 lb (at pivot pin) Loader Breakout Force 1,926 lb 1,531 lbf ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years (6-year total) Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours
