▶ EngineEngine Manufacturer LS Mtron TYM Engine Model L3C19-T5 A1700N4-BUTR_4 Engine Type 3-cylinder, turbocharged diesel, Tier 4 B/Final Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 116 in³ 104.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp 29.5 hp Engine Emissions Constraints Tier 4 EPA Final Tier4 Cooling System Type Pressurized liquid cooling with recirculating bypass Water-cooled Air Cleaner Not Published Not Published Fuel System High pressure common rail Not Published Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.2 gpm 4.4 gpm Total Hydraulic Flow 12.4 gpm (8.2 + 4.2, computed) 12.6 gpm Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 Not Published No. of Optional Remote Valves 1 Up to 2 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 7.13 gal Coolant Capacity 7.5 qt 1.32 gal Crankcase Capacity 5.8 qt 1.14 gal Transmission / Hydraulic System Capacity 8.5 gal 9.77 gal Front Axle Fluid Capacity 6.9 qt 1.69 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity 1,808 lb 3,306.9 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,425 lb Lift Control Type Mechanical Draft Control (MDC) Position control ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle with synchro shift (dry clutch) (standard) Hydrostatic (HST), 3-range No. of Speeds 12 forward, 12 reverse 3 range (HST) Max Travel Speed (Forward) 14.2 mph 19.08 mph Max Travel Speed (Reverse) 13.63 mph 19.08 mph Clutch Dry clutch None (HST) Differential Lock & Limited Slip Options Mechanical differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc, mechanical actuation Wet, multi-disc Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Mechanical Front Drive (MFD) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.2 in 134.88 in Overall Width 66.4 in 56.7 in Wheelbase 67.3 in 65.7 in Ground Clearance 10.0 in 15 in Min. Turn Radius without Brakes 123 in Not Published Height to Top of ROPS 87.6 in 96.85 in Height to Top of ROPS (folded) 68.2 in Not Published Height to Top of Cab Model Not Published 85.9 in ▶ WeightTractor Weight (Base) 3,067 lb 3,163.6 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, or R4 industrial (R4 standard) R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R1 Agricultural - Front 7x14 8.0-16 R1 Agricultural - Rear 11.2x24 12.4-24 R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 25x8.50-14 28x8.50-15 R4 Industrial - Rear 43x16.00-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published SSQA Loader Model L340A BBL400 Loader Lift Height 98.4 in 104 in Loader Lift Capacity (Full Height) 1,250 lb 2,200 lb Loader Breakout Force 1913 lb 3,660 lb ▶ WarrantyWarranty Length & Coverage 6-year extended warranty: 2 years bumper-to-bumper plus 4 additional years of powertrain protection Engine and powertrain 72 months or 2,000 hours; other tractor parts 24 months or 1,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
