▶ EngineEngine Manufacturer LS Mtron LS Engine Model L3C19-T5 L3C19-D2 Engine Type 3-cylinder, turbocharged diesel, Tier 4 B/Final 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 3 3 Displacement 116 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp 29.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid cooling with recirculating bypass Liquid-cooled Air Cleaner Not Published Dry Fuel System High pressure common rail CRDI (Delphi common rail direct injection) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.2 gpm 4.1 gpm Total Hydraulic Flow 12.4 gpm (8.2 + 4.2, computed) 12.3 gpm Overall Hydraulic Pump Flow Not Published 12.3 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 0 No. of Optional Remote Valves 1 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 7.4 gal Coolant Capacity 7.5 qt 1.9 gal Crankcase Capacity 5.8 qt 1.5 gal Transmission / Hydraulic System Capacity 8.5 gal 8.5 gal Front Axle Fluid Capacity 6.9 qt 1.7 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent (wet disc clutch) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Optional, 2,000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Mechanical Draft Control (MDC) Position control ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle with synchro shift (dry clutch) (standard) Synchro Shuttle No. of Speeds 12 forward, 12 reverse F12 x R12 Max Travel Speed (Forward) 14.2 mph 14.33 mph Max Travel Speed (Reverse) 13.63 mph 13.63 mph Clutch Dry clutch Dry single clutch Differential Lock & Limited Slip Options Mechanical differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc, mechanical actuation Wet, multi-disc Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Mechanical Front Drive (MFD) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.2 in 121 in Overall Width 66.4 in 54 in (R1); 66 in (R4) Wheelbase 67.3 in 69 in Ground Clearance 10.0 in Not Published Min. Turn Radius without Brakes 123 in 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 87.6 in 88 in Height to Top of ROPS (folded) 68.2 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,067 lb 2,866 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, or R4 industrial (R4 standard) R1 agricultural, R4 industrial or R3 turf at no extra cost R1 Agricultural - Front 7x14 7-14 R1 Agricultural - Rear 11.2x24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 25x8.50-14 25x8.50-14 R4 Industrial - Rear 43x16.00-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model L340A LL3301 Loader Lift Height 98.4 in LL3301: 94 in Loader Lift Capacity (Full Height) 1,250 lb LL3301: 1,688 lb (at pivot pin, full height) Loader Breakout Force 1913 lb LL3301: 2,855 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year extended warranty: 2 years bumper-to-bumper plus 4 additional years of powertrain protection 6-year limited warranty
