▶ EngineEngine Manufacturer LS Mtron TYM Engine Model Not Published T1700N6 Engine Type 3-cylinder, Tier 4 B/Final 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 114.7 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 31 hp 30 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Not Published Air Cleaner Not Published Dry element Fuel System Not Published IDI (indirect injection) Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 8.4 gpm 7.5 gpm Steering Flow Not Published 4.0 gpm Total Hydraulic Flow 13.3 gpm 11.5 gpm Overall Hydraulic Pump Flow Not Published 11.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 Loader: 4 / Rear: 0 No. of Optional Remote Valves 3 Up to 4 ▶ Fluid CapacityFuel Tank Capacity 12.6 gal 8.7 gal Coolant Capacity Not Published 5.3 qt Crankcase Capacity Not Published 4.5 qt Transmission / Hydraulic System Capacity Not Published T3035R: 8.9 gal; T3035H: 9.8 gal Front Axle Fluid Capacity Not Published 6.8 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 3,307 lb Hitch Lift Capacity (at 24”) 1,596 lb 2,425 lb Lift Control Type Mechanical Draft Control (MDC) Position control ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle with synchro shift (dry clutch) (standard) T3035R: Synchromesh; T3035H: HST No. of Speeds 12 forward, 12 reverse T3035R: F12 x R12; T3035H: 3-Range Max Travel Speed (Forward) 14.2 mph T3035R: 14.4 mph; T3035H: 18.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry clutch T3035R: Dry single plate; T3035H: None (HST) Differential Lock & Limited Slip Options Mechanical differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic Brakes Not Published Wet, multi-disc Seat Suspension & Adjustability Adjustable suspension seat Suspension seat Front Axle Type Mechanical Front Drive (MFD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 56.3 in Wheelbase 66.2 in 65.7 in Ground Clearance Not Published 14.4 in Min. Turn Radius without Brakes 10.5 ft 105.5 in Height to Top of ROPS 96.2 in 97.3 in Height to Top of ROPS (folded) 74.2 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 119.4 in 120.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,042 lb 2,970 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, or R4 Industrial R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24 R1 Agricultural - Front 7x14 8-16 R1 Agricultural - Rear 11.2x24 12.4-24 R3 Turf - Front 25x8.50-14 27x8.5-15 R3 Turf - Rear 41x14.00-20 41x14.00 R4 Industrial - Front 25x8.50-14 10-16.5 R4 Industrial - Rear 43x16.00-20 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model L340A L3035 Loader Lift Height 98 in L3035: 104.9 in Loader Lift Capacity (Full Height) 890 lb at 31.5 in forward of pivot pin L3035: 2,200 lb (at pivot pin) Loader Breakout Force 1,900 lb L3035: 3,422 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years (6-year total) Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months
