▶ EngineEngine Manufacturer Not Published TYM Engine Model Not Published A1700N4-BUTR_4 Engine Type Diesel, 3-cylinder, turbocharged Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 116 in³ 104.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp 29.5 hp Engine Emissions Constraints Tier 4 EPA Final Tier4 Cooling System Type Not Published Water-cooled Air Cleaner Replaceable dry element Not Published Fuel System Common rail direct injection Not Published Alternator 70 A 50 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.2 gpm 4.4 gpm Total Hydraulic Flow Not Published 12.6 gpm Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2 Up to 2 ▶ Fluid CapacityFuel Tank Capacity 10.5 gal 7.13 gal Coolant Capacity Not Published 1.32 gal Crankcase Capacity Not Published 1.14 gal Transmission / Hydraulic System Capacity Not Published 9.77 gal Front Axle Fluid Capacity Not Published 1.69 gal ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity 1,808 lb 3,306.9 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,425 lb Lift Control Type Mechanical draft control (MDC) Position control ▶ Transmission & DrivetrainTransmission Type 12 x 12 mechanical shuttle with synchro shift Hydrostatic (HST), 3-range No. of Speeds 12 forward, 12 reverse 3 range (HST) Max Travel Speed (Forward) 14.2 mph 19.08 mph Max Travel Speed (Reverse) Not Published 19.08 mph Clutch dry clutch None (HST) Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Mechanical Front Drive (MFD) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.5 in 134.88 in Overall Width 66.4 in 56.7 in Wheelbase 66 in 65.7 in Ground Clearance Not Published 15 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 93.5 in 96.85 in Height to Top of ROPS (folded) 74.1 in Not Published Height to Top of Cab Model Not Published 85.9 in ▶ WeightTractor Weight (Base) 3,175 lb 3,163.6 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R1 Agricultural - Front 7-14 8.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 25x8.50-14 28x8.50-15 R4 Industrial - Rear 43x16.00-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; quick-connect loader mounting (L350A) SSQA Loader Model L350A BBL400 Loader Lift Height 105 in 104 in Loader Lift Capacity (Full Height) 2,000 lb 2,200 lb Loader Breakout Force 2,640 lbf 3,660 lb ▶ WarrantyWarranty Length & Coverage 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain Engine and powertrain 72 months or 2,000 hours; other tractor parts 24 months or 1,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
