▶ EngineEngine Manufacturer LS Mtron LS Engine Model Not Published L3C19-T4 Engine Type 3-cylinder, turbocharged diesel, Tier 4 B/Final 3-cylinder, liquid-cooled, diesel, turbocharged (TC), CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 35.9 hp 34 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published CRDI (Delphi common rail direct injection) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, engine driven Implement Flow 8.4 gpm 8.2 gpm Steering Flow Not Published 4.1 gpm Total Hydraulic Flow 13.3 gpm 12.3 gpm Overall Hydraulic Pump Flow Not Published 12.3 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 None No. of Optional Remote Valves 3 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 12.6 gal 7.4 gal Coolant Capacity Not Published 1.9 gal Crankcase Capacity Not Published 1.5 gal Transmission / Hydraulic System Capacity Not Published 8.5 gal Front Axle Fluid Capacity Not Published 1.7 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent (wet disc clutch) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) 1,596 lb 1,433 lb Lift Control Type Mechanical Draft Control (MDC) Position control ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle with synchro shift (dry clutch) (standard) Synchro Shuttle No. of Speeds 12 forward, 12 reverse F12 x R12 Max Travel Speed (Forward) 14.2 mph 14.33 mph Max Travel Speed (Reverse) Not Published 13.63 mph Clutch Dry clutch Dry single clutch Differential Lock & Limited Slip Options Mechanical differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic power steering Brakes Not Published Wet, multi-disc Seat Suspension & Adjustability Adjustable suspension seat Not Published Front Axle Type Mechanical Front Drive (MFD) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 54 in Wheelbase 66.2 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.5 ft 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 96.2 in 88 in Height to Top of ROPS (folded) 74.2 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 119.4 in 121 in (frame to link) ▶ WeightTractor Weight (Base) 3,053 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, or R4 Industrial Ag, industrial or turf tires at no additional cost R1 Agricultural - Front 7x14 7-14 R1 Agricultural - Rear 11.2x24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 25x8.50-14 27x8.50-14 R4 Industrial - Rear 43x16.00-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model L340A LL3302 Loader Lift Height 98 in LL3302: 94 in Loader Lift Capacity (Full Height) 890 lb at 31.5 in. forward of pivot pin LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force 1,900 lb LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years (6-year total) 6-year limited warranty
