▶ EngineEngine Manufacturer LS Mtron Shibaura Engine Model L3C19-T4 Shibaura N3LDI-T Engine Type 3-cylinder, turbocharged diesel, Tier 4 B/Final 3-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 3 3 Displacement 116 in³ 101.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 34 hp 31.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid cooling with recirculating bypass Liquid-cooled Air Cleaner Not Published Dry Fuel System High pressure common rail Common rail direct injection Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear Engine-driven gear-type pump Implement Flow 8.2 gpm 11.0 gpm Steering Flow 4.2 gpm Not Published Total Hydraulic Flow 12.4 gpm (8.2 + 4.2, computed) Not Published Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves 0 2 No. of Optional Remote Valves 1 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 10.56 gal Coolant Capacity 7.5 qt 6.34 qt Crankcase Capacity 5.8 qt 4.86 qt Transmission / Hydraulic System Capacity 8.5 gal 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Front Axle Fluid Capacity 6.9 qt 7.9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent, with soft-start feature PTO Rear 540 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Optional, 2,000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category 1 Category I with extendable ball ends Hitch Lift Capacity 1,808 lb 2,646 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,535 lb Lift Control Type Mechanical Draft Control (MDC) Position and draft control ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle with synchro shift (dry clutch) (standard) 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 12 forward, 12 reverse 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) 14.2 mph Not Published Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry clutch Single stage dry type Differential Lock & Limited Slip Options Mechanical differential lock Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc, mechanical actuation Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Adjustable suspension seat Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type Mechanical Front Drive (MFD) Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.2 in 122.0 in Overall Width 66.5 in 64.2 in Wheelbase 67.2 in 69.7 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes 123 in Not Published Height to Top of ROPS 87.6 in 99.2 in Height to Top of ROPS (folded) 68.2 in Not Published Height to Top of Cab Model Not Published 91.3 in ▶ WeightTractor Weight (Base) 3,067 lb 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, or R4 industrial (R4 standard) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7x14 8-16 R1 Agricultural - Rear 11.2x24 12.4x24 R3 Turf - Front 25x8.50-14 27x8.50-15 R3 Turf - Rear 41x14.00-20 41x14.00-20 R4 Industrial - Front 25x8.50-14 10-16.5 R4 Industrial - Rear 43x16.00-20 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published DL125: Pin-on (skid steer quick attach optional) Loader Model L340A DL125 Loader Lift Height 98.4 in DL125: 106 in Loader Lift Capacity (Full Height) 1,250 lb DL125: 1,660 lb Loader Breakout Force 1913 lb DL125: 3,000 lb ▶ WarrantyWarranty Length & Coverage 6-year extended warranty: 2 years bumper-to-bumper plus 4 additional years of powertrain protection 5-year powertrain warranty
