▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3C19-T4 Not Published Engine Type Diesel, 3-cylinder, turbocharged 3-cylinder, Tier 4 B/Final No. of Cylinders 3 3 Displacement 115.9 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 35 hp PTO Power 32 hp 30.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Not Published Air Cleaner Replaceable dry element Not Published Fuel System Common rail direct injection Not Published Alternator 70 A 85 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.2 gpm 8.4 gpm Steering Flow 5.3 gpm Not Published Total Hydraulic Flow 13.5 gpm (8.2 + 5.3, computed) 13.3 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 0 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 12.4 gal 12.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,808 lb 1,596 lb Lift Control Type Mechanical draft control (MDC) Mechanical Draft Control (MDC) ▶ Transmission & DrivetrainTransmission Type 3-range hydrostatic (optional) 3-range hydrostatic (optional) No. of Speeds 3 ranges 3 ranges Max Travel Speed (Forward) 14.8 mph 14.8 mph (with R4 tires) Max Travel Speed (Reverse) Not Published Not Published Clutch n/a (no clutch on hydrostatic) n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Mechanical differential lock Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Not Published Brakes Wet multi-disc Not Published Seat Suspension & Adjustability Deluxe seat with armrests and an adjustable backrest Adjustable suspension seat Front Axle Type Mechanical Front Drive (MFD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.4 in 66.5 in Wheelbase 66 in 66.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 10.5 ft Height to Top of ROPS Not Applicable 96.2 in Height to Top of ROPS (folded) Not Applicable 74.2 in Height to Top of Cab Model 93.3 in Not Published Overall Length 128.1 in 119.4 in ▶ WeightTractor Weight (Base) 3,803 lb 3,042 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, or R4 Industrial R1 Agricultural - Front Not Published 7x14 R1 Agricultural - Rear Not Published 11.2x24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; mid-mount frame for fast loader connect and disconnect (L350A) Not Published Loader Model L350A L340A Loader Lift Height 105 in 98 in Loader Lift Capacity (Full Height) 1,540 lb at 31.5 in. forward of pivot pin 890 lb at 31.5 in forward of pivot pin Loader Breakout Force 2,640 lbf 1,900 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years (6-year, 72-month total) Basic 2 years; powertrain 4 additional years (6-year total)
