▶ EngineEngine Manufacturer Not Published LS Engine Model Not Published L3C19-T Engine Type Diesel, 3-cylinder, turbocharged 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 3 3 Displacement 116 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 34 hp 34 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Replaceable dry element Dry Fuel System Common rail direct injection CRDI (Delphi common rail direct injection) Alternator 70 A 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.2 gpm 5.5 gpm Total Hydraulic Flow Not Published 13.7 gpm Overall Hydraulic Pump Flow Not Published 13.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 0 No. of Optional Remote Valves Not Published 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 12.4 gal 7.4 gal Coolant Capacity Not Published 1.9 gal Crankcase Capacity Not Published 1.5 gal Transmission / Hydraulic System Capacity Not Published 8.5 gal Front Axle Fluid Capacity Not Published 1.7 gal ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent (wet disc clutch) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Mechanical draft control (MDC) Position control ▶ Transmission & DrivetrainTransmission Type 12 x 12 mechanical shuttle with synchro shift Synchro Shuttle No. of Speeds 12 forward, 12 reverse F12 x R12 Max Travel Speed (Forward) 14.2 mph 14.33 mph Max Travel Speed (Reverse) Not Published 13.63 mph Clutch dry clutch Dry single clutch Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Deluxe cloth seat with adjustable suspension Not Published Front Axle Type Mechanical Front Drive (MFD) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.1 in 121 in Overall Width 66.4 in 54 in (R1); 66 in (R4) Wheelbase 66 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS Not Published 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in Not Published ▶ WeightTractor Weight (Base) 3,803 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 agricultural, R4 industrial or R3 turf at no extra cost R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; quick-connect loader mounting (L350A) Not Published Loader Model L350A LL3302 Loader Lift Height 105 in LL3302: 94 in Loader Lift Capacity (Full Height) 2,000 lb LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force 2,640 lbf LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain 6-year limited warranty
