▶ EngineEngine Manufacturer Not Published LS Engine Model Not Published L3C19-T4 Engine Type Diesel, 3-cylinder, turbocharged 4-stroke, vertical, water cooling, CRDI No. of Cylinders 3 3 Displacement 116 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 34 hp 34.4 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Not Published Water-cooled Air Cleaner Replaceable dry element Dry Fuel System Common rail direct injection Delphi CRDI (Common Rail Direct Injection) Alternator 70 A 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump type, engine drive Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.2 gpm 4.1 gpm (mechanical); 5.5 gpm (HST) Total Hydraulic Flow Not Published 12.3 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 12.4 gal 10.6 gal (roll-bar); 12.4 gal (cabin) Coolant Capacity Not Published 2.3 gal Crankcase Capacity Not Published 1.6 gal Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 2.1 gal ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent PTO with wet disk clutch PTO Rear 540 rpm 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Mid-PTO Availability Optional, 2000 rpm Yes, 2000 rpm mid-PTO Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity 1,808 lb 2,756 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,469 lb Lift Control Type Mechanical draft control (MDC) Position and draft control ▶ Transmission & DrivetrainTransmission Type 12 x 12 mechanical shuttle with synchro shift Synchro-shuttle (mechanical) No. of Speeds 12 forward, 12 reverse F16 x R16 (F32 x R16 with creeper, optional) Max Travel Speed (Forward) 14.2 mph 16.8 mph Max Travel Speed (Reverse) Not Published 15.3 mph Clutch dry clutch Dry single clutch (mechanical only) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical pedal type differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet multi-disc Wet disc Seat Suspension & Adjustability Deluxe cloth seat with adjustable suspension Not Published Front Axle Type Mechanical Front Drive (MFD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.1 in 133 in Overall Width 66.4 in 62.5 in Wheelbase 66 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 9.5 ft (with brake applied) Height to Top of ROPS Not Published 93 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in 92 in ▶ WeightTractor Weight (Base) 3,803 lb Roll-bar: 3,770 lb; Cabin: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural - Front Not Published 9.5-16 (6PR) R1 Agricultural - Rear Not Published 13.6-24 (8PR) R3 Turf - Front Not Published 28x8.5-15 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; quick-connect loader mounting (L350A) Not Published Loader Model L350A LL4104 Loader Lift Height 105 in LL4104: 96.3 in Loader Lift Capacity (Full Height) 2,000 lb LL4104: 2,713 lb Loader Breakout Force 2,640 lbf LL4104: 3,802 lb ▶ WarrantyWarranty Length & Coverage 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
