▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3C19-T4 L3CRV-T4 Engine Type Not Published 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 115.9 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 34 hp Gear: 34 hp; HST: 32 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Not Published Liquid cooled Air Cleaner Replaceable dry element Replaceable primary and inner elements Fuel System Not Published Electronically controlled common rail direct injection Alternator 70 A ROPS: 70 A, 12 V; Cab: 85 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.2 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 12.4 gpm (8.2 + 4.2, computed) Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 12.4 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity Not Published 7.5 qt Crankcase Capacity Not Published 5.8 qt Transmission / Hydraulic System Capacity Not Published 8.5 gal Front Axle Fluid Capacity Not Published 6.87 qt ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) 1,808 lb 1,345 lb Lift Control Type Mechanical draft control (MDC) Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type 12 x 12 mechanical shuttle with synchro shift Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 12 forward, 12 reverse Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) 14.2 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) Not Published Gear: 13.63 mph; HST: 13.60 mph Clutch dry clutch Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Mechanical differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Deluxe seat with armrests and an adjustable backrest ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth seat with weight control, easy fore/aft movement and adjustable armrests Front Axle Type Mechanical Front Drive (MFD) Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.4 in 66.4 in Wheelbase 66 in 66 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS Not Published 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in 90 in Overall Length 128.1 in 119 in ▶ WeightTractor Weight (Base) 3,803 lb ROPS Gear: 2,804 lb; ROPS HST: 2,870 lb; Cab: 3,574 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; mid-mount frame for fast loader connect and disconnect (L350A) Tool-free loader mount; optional skid-steer quick-attach plates Loader Model L350A 250TLA Loader Lift Height 105 in 250TLA: 104 in (at pivot pin) Loader Lift Capacity (Full Height) 1,540 lb at 31.5 in. forward of pivot pin 250TLA: 1,822 lb (at bucket pivot pin, max height) Loader Breakout Force 2,640 lbf 250TLA: 3,257 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years (6-year, 72-month total) Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
