▶ EngineEngine Manufacturer LS Mtron KIOTI Engine Model L3C19-T 3F183T Engine Type Not Published 3-cylinder, turbocharged, common-rail, liquid-cooled diesel No. of Cylinders 3 3 Displacement 115.9 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38.2 hp 33.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Replaceable dry element Dry type element Fuel System Not Published Common Rail Diesel (CRDI) Alternator 70 A Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm Not Published Steering Flow 4.2 gpm Not Published Total Hydraulic Flow 12.4 gpm (8.2 + 4.2, computed) 17.9 gpm Overall Hydraulic Pump Flow Not Published 17.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 12.4 gal 14.8 gal Coolant Capacity Not Published 2.0 gal Crankcase Capacity Not Published 1.58 gal Transmission / Hydraulic System Capacity Not Published 11.89 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 3,538 lb Hitch Lift Capacity (at 24”) 2,756 lb 3,177 lb Lift Control Type Mechanical draft control (MDC) Position with Draft Control ▶ Transmission & DrivetrainTransmission Type 16 x 16 mechanical shuttle with synchro shift Hydrostatic No. of Speeds 16 forward, 16 reverse 3 Range Max Travel Speed (Forward) 16.9 mph 16.52 mph Max Travel Speed (Reverse) Not Published 16.52 mph Clutch dry clutch Not Published Differential Lock & Limited Slip Options Mechanical differential lock Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Wet multi-disc Wet Multi Disc Seat Suspension & Adjustability Deluxe seat with armrests and an adjustable backrest Adjustable Seat Front Axle Type Mechanical Front Drive (MFD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Width 69.1 in 65.6 in Wheelbase 73.2 in 75.6 in Ground Clearance Not Published 13.8 in Min. Turn Radius without Brakes Not Published 9.8 ft Height to Top of ROPS Not Published 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in Not Published Overall Length 128.1 in 139.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4,453 lb 4,000 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Agricultural, Turf, Industrial R1 Agricultural - Front 9.5-16 8-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 28x8.50-15 29-12.5-15 R3 Turf - Rear 41x14.00-20 21.5L-16.1 R4 Industrial - Front 12-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; mid-mount frame for fast loader connect and disconnect (L360A) Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model L360A KL6010 Loader Lift Height 112 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) 1,830 lb at 31.5 in. forward of pivot pin KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force 3,114 lbf KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years (6-year, 72-month total) Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
