▶ EngineEngine Manufacturer LS Mtron Mahindra Engine Model L3C19-T Not Published Engine Type Diesel, 3-cylinder, turbocharged Four-stroke, naturally aspirated, direct injection, water cooled diesel No. of Cylinders 3 4 Displacement 116 in³ 166.2 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38.2 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Replaceable dry element Not Published Fuel System Common rail direct injection Direct injection Alternator 70 A 55 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.2 gpm 8.71 gpm Steering Flow 4.2 gpm 4.62 gpm Total Hydraulic Flow Not Published 13.3 gpm Overall Hydraulic Pump Flow Not Published 13.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 12.4 gal 17.1 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category 1 CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity 2,756 lb Not Published Hitch Lift Capacity (at 24”) 2,469 lb 3748 lb Lift Control Type Mechanical draft control (MDC) Position control ▶ Transmission & DrivetrainTransmission Type 16 x 16 mechanical shuttle with synchro shift Full synchromesh with forward/reverse synchro shuttle & constant mesh range No. of Speeds 16 forward, 16 reverse 12F / 12R Max Travel Speed (Forward) 16.9 mph 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch dry clutch Dual dry with cerametallic lining Differential Lock & Limited Slip Options Mechanical rear differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering with tilt steering wheel Brakes Wet multi-disc Fully-enclosed, 7-in diameter, dry disc Seat Suspension & Adjustability Adjustable suspension seat Adjustable seat with contoured cushions, armrests and a soft-coil suspension Front Axle Type Mechanical Front Drive (MFD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.1 in 136.6 in Overall Width 69.1 in 74.8 in Wheelbase 73.2 in 77.9 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes Not Published 10.8 ft Height to Top of ROPS 97.1 in Not Published Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 93.3 in Not Published ▶ WeightTractor Weight (Base) 4,453 lb 5390 lb Weight with ROPS and Loader Not Published 6,690 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural or R4 Industrial R1 Agricultural - Front 9.5-16 9.5 x 20 R1 Agricultural - Rear 13.6-24 14.9 x 28 R3 Turf - Front 28x8.50-15 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 12-16.5 10.5/80 x 18 R4 Industrial - Rear 17.5L-24 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; quick-connect loader mounting (L360A) Skid-steer style quick-attach coupler Loader Model L360A 5155-4L (front loader); 65B (rear backhoe) Loader Lift Height 112 in 5155-4L: 122 in Loader Lift Capacity (Full Height) 2,500 lb 5155-4L: 3,100 lb Loader Breakout Force 3,114 lbf 5155-4L: 5,200 lb ▶ WarrantyWarranty Length & Coverage 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain 5-year limited powertrain warranty
