▶ EngineEngine Manufacturer FPT Mitsubishi Engine Model R 753 IE4 K39 Engine Type 3-cylinder, FPT turbocharged & aftercooled 4-cylinder turbocharged and intercooled diesel No. of Cylinders 3 4 Displacement 135.9 in³ 134.7 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 53 hp 53.6 hp PTO Power 45 hp Gear: 42.1 hp; HST: 40.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Electronic high pressure common rail Common-rail, direct injection, electronic engine management Alternator 75 A Not Published ▶ HydraulicsPump Type Engine-driven dual gear-type Engine-driven gear-type pump Implement Flow 11.9 gpm 11.6 gpm Steering Flow 5.5 gpm 6.8 gpm Total Hydraulic Flow 17.4 gpm (11.9 + 5.5, computed) Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.6 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 14.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulically engaged PTO Rear 540 / 540E 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I/II Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,701 lb 3,086 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position control; draft control optional ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical shuttle (dry clutch) 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST No. of Speeds 8 forward / 8 reverse Power shuttle: 12F / 12R; Servo-HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry clutch Wet multi-disc (power shuttle) Differential Lock & Limited Slip Options Mechanical rear differential lock; limited-slip MFD front axle Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Drop-axle rear with bull gear final drives Steering Hydrostatic steering Power steering, tilt steering wheel Brakes Wet disc Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Not Published Suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Front Axle Type 2WD or MFD with limited slip Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 67.5 in 65.4 in Wheelbase MFD: 77.7 in; 2WD: 77.5 in 77.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes MFD: 190.9 in; 2WD: 135.8 in Not Published Height to Top of ROPS MFD: 97.4 in; 2WD: 92.7 in Not Published Height to Top of ROPS (folded) 75.9 in Not Published Height to Top of Cab Model Not Published 92.9 in Overall Length MFD: 134.0 in; 2WD: 129.5 in 132.3 in ▶ WeightTractor Weight (Base) MFD: 5,060 lb; 2WD: 4,442 lb ROPS: 4,145 lb; Cab: 4,575 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (bar tread) or R4 industrial tread Ag: 9.5x16 front, 13.6x28 rear (16.9x24 optional); turf: 27x10.50-15 front, 44x18.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/80R16 front, 360/80R28 rear) R1 Agricultural - Front MFD: 8.3x24; 2WD: 7.5x16 9.5-16 R1 Agricultural - Rear MFD: 13.6x28; 2WD: 13.6x28 13.6-28 (16.9-24 optional) R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front MFD: 12.5x18 10-16.5 or 250/80R16 R4 Industrial - Rear MFD: 18.4x24 17.5L-24 or 360/80R28 ▶ Loader & AttachmentsQuick Attach Loader System Compatible loaders: L545, L555 DL135: universal skid steer or exclusive compact quick-attach implement tool carrier Loader Model L545; L555 DL135 Loader Lift Height L545: 106 in; L555: 105 in DL135: 110.2 in (at pivot pin) Loader Lift Capacity (Full Height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb DL135: 2,420 lb (at pivot pin, full height) Loader Breakout Force L545: 3,131 lb; L555: 3,527 lb DL135: 2,860 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
