▶ EngineEngine Manufacturer FPT Iseki Engine Model Not Published Iseki E4FH Engine Type 3-cylinder, FPT turbocharged & aftercooled 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 4 Displacement 135.9 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 53 hp 53.6 hp PTO Power 45 hp 40 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry Dry Fuel System Electronic high pressure common rail Common rail direct injection Alternator 75 A Not Published ▶ HydraulicsPump Type Engine-driven dual gear-type Two gear-type pumps for steering and 3-point/remotes Implement Flow 11.9 gpm 12.6 gpm Steering Flow 5.5 gpm 7 gpm Total Hydraulic Flow 17.4 gpm (11.9 + 5.5, computed) 19.6 gpm (12.6 + 7, computed) Overall Hydraulic Pump Flow Not Published 19.6 gpm (12.6 + 7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 14.0 gal Coolant Capacity Not Published 7.61 qt Crankcase Capacity Not Published 7.82 qt Transmission / Hydraulic System Capacity Not Published 10.04 gal Front Axle Fluid Capacity Not Published 9 qt ▶ PTO & HitchPTO Type Independent Independent with SoftStart electronic modulation PTO Rear 540 / 540E 540 rpm (1-3/8 in) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category 1/2 Category I and II Hitch Lift Capacity Not Published 3,483 lb Hitch Lift Capacity (at 24”) 2,701 lb 3,086 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Not Published ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical shuttle (dry clutch) 12x12 power shuttle No. of Speeds 8 forward / 8 reverse 12 forward and 12 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry clutch Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock; limited-slip MFD front axle Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests Front Axle Type 2WD or MFD with limited slip Solid cast front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch MFD: 134.0 in; 2WD: 129.5 in 132.3 in Overall Width 67.5 in 70.1 in Wheelbase MFD: 77.7 in; 2WD: 77.5 in Not Published Ground Clearance Not Published 14.0 in Min. Turn Radius without Brakes MFD: 190.9 in; 2WD: 135.8 in Not Published Height to Top of ROPS MFD: 97.4 in; 2WD: 92.7 in 102.4 in Height to Top of ROPS (folded) 75.9 in Not Published Height to Top of Cab Model Not Published 92.9 in ▶ WeightTractor Weight (Base) MFD: 5,060 lb; 2WD: 4,442 lb ROPS: 4,035 lb; Cab: 4,420 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (bar tread) or R4 industrial tread R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front MFD: 8.3x24; 2WD: 7.5x16 9.5-16 R1 Agricultural - Rear MFD: 13.6x28; 2WD: 13.6x28 13.6-28 standard; 16.9-24 optional R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front MFD: 12.5x18 10-16.5 R4 Industrial - Rear MFD: 18.4x24 14.9-24; 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Compatible loaders: L545, L555 FL2814: pin-type or skid steer Loader Model L545; L555 FL2814 Loader Lift Height L545: 106 in; L555: 105 in FL2814: 111 in Loader Lift Capacity (Full Height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb FL2814: 2,570 lb Loader Breakout Force L545: 3,131 lb; L555: 3,527 lb FL2814: 3,910 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
