▶ EngineEngine Manufacturer FPT Shibaura Engine Model Not Published Shibaura N4LDI-TA Engine Type 3-cylinder, FPT turbocharged & aftercooled 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 3 4 Displacement 135.9 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 53 hp 53.9 hp PTO Power 45 hp 41.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Electronic high pressure common rail Common rail direct injection Alternator 75 A Not Published ▶ HydraulicsPump Type Engine-driven dual gear-type Engine-driven gear-type pump Implement Flow 11.9 gpm 12.7 gpm Steering Flow 5.5 gpm Not Published Total Hydraulic Flow 17.4 gpm (11.9 + 5.5, computed) Not Published Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 14.0 gal Coolant Capacity Not Published 7.08 qt Crankcase Capacity Not Published 6.87 qt Transmission / Hydraulic System Capacity Not Published 12x12 Power Shuttle: 10.04 gal; HST: 9.25 gal Front Axle Fluid Capacity Not Published 9.0 qt ▶ PTO & HitchPTO Type Independent Independent, with soft-start feature PTO Rear 540 / 540E 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category 1/2 Category I with extendable ball ends Hitch Lift Capacity Not Published 3,483 lb Hitch Lift Capacity (at 24”) 2,701 lb 3,086 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position and draft control ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical shuttle (dry clutch) 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 8 forward / 8 reverse 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry clutch Single stage dry type Differential Lock & Limited Slip Options Mechanical rear differential lock; limited-slip MFD front axle Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Not Published Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type 2WD or MFD with limited slip Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch MFD: 134.0 in; 2WD: 129.5 in 132.3 in Overall Width 67.5 in 65.4 in Wheelbase MFD: 77.7 in; 2WD: 77.5 in 77.9 in Ground Clearance Not Published 14.8 in Min. Turn Radius without Brakes MFD: 190.9 in; 2WD: 135.8 in Not Published Height to Top of ROPS MFD: 97.4 in; 2WD: 92.7 in 102.4 in Height to Top of ROPS (folded) 75.9 in Not Published Height to Top of Cab Model Not Published 92.9 in ▶ WeightTractor Weight (Base) MFD: 5,060 lb; 2WD: 4,442 lb 12x12 Power Shuttle: 3,968 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (bar tread) or R4 industrial tread R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front MFD: 8.3x24; 2WD: 7.5x16 9.5x16 R1 Agricultural - Rear MFD: 13.6x28; 2WD: 13.6x28 13.6x28 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front MFD: 12.5x18 10-16.5 R4 Industrial - Rear MFD: 18.4x24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Compatible loaders: L545, L555 DL135: Skid steer quick attach Loader Model L545; L555 DL135 Loader Lift Height L545: 106 in; L555: 105 in DL135: 111 in Loader Lift Capacity (Full Height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb DL135: 2,610 lb Loader Breakout Force L545: 3,131 lb; L555: 3,527 lb DL135: 4,000 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
