▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model Not Published L3CRV-T8 Engine Type Diesel, 3-cylinder, turbocharged 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 115.9 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 40 hp Gear: 42.5 hp; HST: 40 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Not Published Liquid cooled Air Cleaner Not Published Replaceable primary and inner elements Fuel System Not Published Electronically controlled common rail direct injection Alternator Not Published ROPS: 70 A; Cab: 85 A ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm 8.2 gpm Steering Flow Not Published Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 13.5 gpm (8.2 + 5.3, computed) Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 12.4 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity Not Published 2.3 gal Crankcase Capacity Not Published 5.8 qt Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 2.2 gal ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 2,756 lb Hitch Lift Capacity (at 24”) Not Published 2,116 lb Lift Control Type Mechanical draft control (MDC) Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type 3-range hydrostatic (HST) Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds infinitely variable, 3 ranges Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) Not Published Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) Not Published Gear: 15.3 mph; HST: 11.37 mph Clutch Not Applicable Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Wet multi-disc Seat Suspension & Adjustability Adjustable suspension seat ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type Mechanical Front Drive (MFD) Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Width Not Published 69.1 in Wheelbase 73.2 in 73.2 in Ground Clearance Not Published 15 in Min. Turn Radius without Brakes Not Published 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS Not Published 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in 94 in Overall Length 128.1 in 128.1 in ▶ WeightTractor Weight (Base) 4,453 lb ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 9.5-16 R1 Agricultural - Rear Not Published 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 12x16.5 R4 Industrial - Rear Not Published 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate Tool-free loader mount; optional skid-steer quick-attach plates Loader Model L360A 260TLA Loader Lift Height 112 in 260TLA: 109 in (at pivot pin) Loader Lift Capacity (Full Height) 1,830 lb at 31.5 in. forward of pivot pin (L360A) 260TLA: 2,371 lb (at bucket pivot pin, max height) Loader Breakout Force 3,114 lbf 260TLA: 4,081 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
