▶ EngineEngine Manufacturer Not Published FPT Engine Model Not Published Not Published Engine Type Diesel, 3-cylinder, turbocharged 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final No. of Cylinders 3 3 Displacement 116 in³ 178.8 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 50 hp 54 hp PTO Power 42.5 hp 40 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common rail direct injection Electronic high pressure common rail Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Fixed displacement Implement Flow 8.2 gpm 12.6 gpm Steering Flow Not Published Not Published Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 3 ▶ Fluid CapacityFuel Tank Capacity 10.5 gal 21.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 (standard); 540/540E (optional) Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category 1 Category 1/2 Hitch Lift Capacity 2,756 lb 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) Not Published 4,300 lb (optional hitch 4,740 lb) Lift Control Type Mechanical draft control (MDC) Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type 16 x 16 mechanical shuttle with synchro shift MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds 16 forward, 16 reverse MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published Not Published Clutch dry clutch MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle); optional dry clutch (12x12 mechanical shuttle) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic Brakes Not Published Wet disc Seat Suspension & Adjustability Adjustable suspension seat Mechanical contoured seat, adjustable; optional air-ride seat Front Axle Type Mechanical Front Drive (MFD) 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.1 in 155.3 in Overall Width Not Published Not Published Wheelbase 73.2 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 97.1 in Not Published Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 93.3 in 2WD: 98 in; MFD: 100 in ▶ WeightTractor Weight (Base) 3,770 lb 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front Not Published 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear Not Published 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; quick-connect loader mounting (L360A) Not Published Loader Model L360A L610 Loader Lift Height 112 in 130.3 in Loader Lift Capacity (Full Height) 2,500 lb NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force 3,114 lbf Not Published ▶ WarrantyWarranty Length & Coverage 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain Not Published
