▶ EngineEngine Manufacturer Not Published John Deere Engine Model Not Published Not Published Engine Type Diesel, 3-cylinder, turbocharged Diesel, turbocharged No. of Cylinders 3 3 Displacement 116 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 42.5 hp 37 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid cooled with overflow reservoir Air Cleaner Not Published Dry type with safety element Fuel System Common rail direct injection Electronically controlled, high-pressure common rail Alternator Not Published 70 A ▶ HydraulicsPump Type Not Published Tandem gear pump (implement + steering) Implement Flow 8.2 gpm 11.4 gpm Steering Flow Not Published 6.8 gpm Total Hydraulic Flow Not Published 18.2 gpm Overall Hydraulic Pump Flow Not Published 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 10.5 gal 19.6 gal Coolant Capacity Not Published Open operator station: 2.85 gal Crankcase Capacity Not Published 9.0 qt (with filter) Transmission / Hydraulic System Capacity Not Published 8.36 gal (9x3) Front Axle Fluid Capacity Not Published 2WD: 16.1 qt; MFWD: 8.0 qt ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent, mechanical engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category 1 Category 2, convertible to 1 Hitch Lift Capacity 2,756 lb 3,968 lb Hitch Lift Capacity (at 24”) Not Published 3,192 lb Lift Control Type Mechanical draft control (MDC) Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type 16 x 16 mechanical shuttle with synchro shift SyncShuttle No. of Speeds 16 forward, 16 reverse 9F/3R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch dry clutch Dual clutch, 11 in (PowrReverser) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Adjustable suspension seat Deluxe adjustable vinyl seat with retractable seat belt Front Axle Type Mechanical Front Drive (MFD) 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.1 in 143.3 in Overall Width Not Published Not Published Wheelbase 73.2 in 80.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS 97.1 in Not Published Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 93.3 in Not Published ▶ WeightTractor Weight (Base) 3,770 lb 5,335 to 5,809 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural - Front Not Published 11L-15 R1 Agricultural - Rear Not Published 14.9-28 R3 Turf - Front Not Published 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) R3 Turf - Rear Not Published 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R4 Industrial - Front Not Published 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R4 Industrial - Rear Not Published 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; quick-connect loader mounting (L360A) 512 or 520M Loader Model L360A 512 or 520M Loader Lift Height 112 in 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) 2,500 lb 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force 3,114 lbf 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
