▶ EngineEngine Manufacturer FPT KIOTI (Daedong) Engine Model Not Published 4A220T Engine Type 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final Indirect injection, vertical, water-cooled, turbocharged 4-cycle diesel No. of Cylinders 3 4 Displacement 178.8 in³ 134.1 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 54 hp 54 hp PTO Power 40 hp 45.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published High efficiency air filter with cyclone pre-cleaner canister Fuel System Electronic high pressure common rail Indirect injection Alternator 120 A 50 A, 12 V ▶ HydraulicsPump Type Fixed displacement Tandem gear Implement Flow 12.6 gpm 9.88 gpm Steering Flow Not Published 4.33 gpm Total Hydraulic Flow Not Published 14.2 gpm Overall Hydraulic Pump Flow Not Published 14.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 18.0 gal Coolant Capacity Not Published 2.51 gal Crankcase Capacity Not Published 2.25 gal Transmission / Hydraulic System Capacity Not Published 10.0 gal Front Axle Fluid Capacity Not Published 2.17 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 (standard); 540/540E (optional) 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1/2 Category II (Category I ends optional) Hitch Lift Capacity 5,952 lb (optional hitch 6,614 lb) Not Published Hitch Lift Capacity (at 24”) 4,300 lb (optional hitch 4,740 lb) 2,654 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) Synchronized shuttle No. of Speeds MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper 12F/12R Max Travel Speed (Forward) 18.6 mph 16.42 mph Max Travel Speed (Reverse) Not Published 13.59 mph Clutch MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle); optional dry clutch (12x12 mechanical shuttle) Dry type single plate, single stage Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet disc type Seat Suspension & Adjustability Mechanical contoured seat, adjustable; optional air-ride seat Adjustable seat Front Axle Type 2WD or MFD with limited slip 4WD (bevel gear front wheel drive, push-button engagement) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.3 in 128.6 in Overall Width Not Published 69.3 in Wheelbase 2WD: 82.1 in; MFD: 83.6 in 75.6 in Ground Clearance Not Published 17.5 in Min. Turn Radius without Brakes Not Published 145 in Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published 85.5 in Height to Top of Cab Model 2WD: 98 in; MFD: 100 in 97.2 in ▶ WeightTractor Weight (Base) 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb 4,795 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 2WD: 9.5L-15; MFD: 11.2x24 9.5-20 R1 Agricultural - Rear 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) 14.9-28 R3 Turf - Front Not Published 29x12.5-15 R3 Turf - Rear Not Published 44x18-20 R4 Industrial - Front Not Published 14x17.5 R4 Industrial - Rear Not Published 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published KL551: universal quick-attach bucket mount, 78 in QA bucket Loader Model L610 KL551; KL1595 Loader Lift Height 130.3 in KL551: 113.58 in; KL1595: 127.52 in Loader Lift Capacity (Full Height) NSL: 1,828 lb; MSL: 3,153 lb KL551: 2,850 lb; KL1595: 2,685 lb Loader Breakout Force Not Published KL551: 4,675 lb; KL1595: 4,500 lb ▶ WarrantyWarranty Length & Coverage Not Published Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
