▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model Not Published n/a Engine Type 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 3 3 Displacement 178.8 in³ 136 in³ Rated Engine Speed 2300 rpm 2600 rpm Engine Power (Gross) 54 hp 53.7 hp PTO Power 40 hp 46.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Pressurized liquid with recirculating bypass Air Cleaner Not Published Inner and outer paper elements Fuel System Electronic high pressure common rail CRDI Alternator 120 A 75 A, 12 V ▶ HydraulicsPump Type Fixed displacement Open-center; dual pumps Implement Flow 12.6 gpm 12 gpm Steering Flow Not Published 5.5 gpm Total Hydraulic Flow Not Published 17.5 gpm Overall Hydraulic Pump Flow Not Published 17.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 3 2 ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 17.2 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 6.7 qt Transmission / Hydraulic System Capacity Not Published 6.6 gal Front Axle Fluid Capacity Not Published 8.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 (standard); 540/540E (optional) 540 rpm Mid-PTO Availability Not Published Not Applicable Category, 3-Point Hitch Category 1/2 Category II/I Hitch Lift Capacity 5,952 lb (optional hitch 6,614 lb) 3,307 lb at ball ends Hitch Lift Capacity (at 24”) 4,300 lb (optional hitch 4,740 lb) 2,701 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Not Published ▶ Transmission & DrivetrainTransmission Type MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) 8x8 synchronized shuttle No. of Speeds MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper 8F/8R Max Travel Speed (Forward) 18.6 mph 19.8 mph Max Travel Speed (Reverse) Not Published 20.9 mph Clutch MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle); optional dry clutch (12x12 mechanical shuttle) LUK, 11 in Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle Rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Brakes Wet disc Wet disc Seat Suspension & Adjustability Mechanical contoured seat, adjustable; optional air-ride seat Not Published Front Axle Type 2WD or MFD with limited slip Not Published Front Axle Rating Not Published 6,500 lb dynamic capacity Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.3 in 134.0 in Overall Width Not Published 67.5 in Wheelbase 2WD: 82.1 in; MFD: 83.6 in 77.2 in Ground Clearance Not Published 15.9 in Min. Turn Radius without Brakes Not Published 190.9 in Height to Top of ROPS Not Published 97.6 in Height to Top of ROPS (folded) Not Published 77.0 in Height to Top of Cab Model 2WD: 98 in; MFD: 100 in 105.4 in ▶ WeightTractor Weight (Base) 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb n/a Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural, R4 Industrial R1 Agricultural - Front 2WD: 9.5L-15; MFD: 11.2x24 8.3X24, 6 ply R1 Agricultural - Rear 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) 13.6X28R1, 6 ply; 14.9X28R1, 6 ply R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5X18 R4 Industrial - Rear Not Published 18.4X24R4 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 600TL: Front loader (quick-attach design) Loader Model L610 n/a Loader Lift Height 130.3 in Up to 122 in Loader Lift Capacity (Full Height) NSL: 1,828 lb; MSL: 3,153 lb Up to 3,130 lb Loader Breakout Force Not Published Up to 3,527 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
