▶ EngineEngine Manufacturer LS Mtron KIOTI (Daedong) Engine Model L3C19-T 3F183T Engine Type Diesel, 3-cylinder, turbocharged KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 3 3 Displacement 116 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 46.7 hp 43.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Replaceable dry element Dry type element Fuel System Common rail direct injection Common Rail Direct Injection (CRDI) Alternator 70 A Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm 9.6 gpm Steering Flow 4.2 gpm 8.2 gpm Total Hydraulic Flow Not Published 17.9 gpm Overall Hydraulic Pump Flow Not Published 17.9 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 10.5 gal 14.8 gal Coolant Capacity Not Published 2.0 gal Crankcase Capacity Not Published 1.58 gal Transmission / Hydraulic System Capacity Not Published 11.89 gal Front Axle Fluid Capacity Not Published 1.8 gal ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category 1 Category I & II Hitch Lift Capacity 2,756 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,469 lb 3,177 lb Lift Control Type Mechanical draft control (MDC) Position with Draft Control ▶ Transmission & DrivetrainTransmission Type 16 x 16 mechanical shuttle with synchro shift Hydrostatic No. of Speeds 16 forward, 16 reverse 3 Range Max Travel Speed (Forward) 16.9 mph 18.26 mph Max Travel Speed (Reverse) Not Published 18.26 mph Clutch dry clutch Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Wet multi-disc Wet Multi Disc Seat Suspension & Adjustability Adjustable suspension seat Adjustable Seat Front Axle Type Mechanical Front Drive (MFD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.1 in 139.6 in Overall Width 69.1 in 65.7 in Wheelbase 73.2 in 75.6 in Ground Clearance Not Published 15.7 in Min. Turn Radius without Brakes Not Published 10.0 ft Height to Top of ROPS 97.1 in Not Published Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 93.3 in 94.1 in ▶ WeightTractor Weight (Base) 3,770 lb 4,529 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 16.9-24 R3 Turf - Front 28x8.50-15 29-12.5-15 R3 Turf - Rear 41x14.00-20 21.5L-16.1 R4 Industrial - Front 12-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate; quick-connect loader mounting (L360A) Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model L360A KL6010 Loader Lift Height 112 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) 2,500 lb KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force 3,114 lbf KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
