▶ EngineEngine Manufacturer LS Mtron Kubota Engine Model L3C19-T V3307-DI Engine Type Diesel, 3-cylinder, turbocharged 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 115.9 in³ 203 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 46.7 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Replaceable dry element 8 in dry, dual element Fuel System Not Published Direct injection Alternator 70 A ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 8.2 gpm 11.0 gpm Steering Flow 4.2 gpm 6.1 gpm Total Hydraulic Flow 12.4 gpm (8.2 + 4.2, computed) 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow Not Published 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 10.5 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 11.6 qt Transmission / Hydraulic System Capacity Not Published 59.2 qt Front Axle Fluid Capacity Not Published Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic engagement Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 2,756 lb 3,307 lb Lift Control Type Mechanical draft control (MDC) Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 16 x 16 mechanical shuttle with synchro shift Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 16 forward, 16 reverse 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 16.9 mph 17.8 mph Max Travel Speed (Reverse) Not Published 18.0 mph Clutch dry clutch Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Power steering Hydrostatic power steering Brakes Wet multi-disc Multiple wet disc, mechanical Seat Suspension & Adjustability Adjustable suspension seat Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Mechanical Front Drive (MFD) 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 69.1 in 73.2 in Wheelbase 73.2 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 97.1 in 96.9 in Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model Not Applicable 99.8 in Overall Length 128.1 in 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 3,770 lb 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5-16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 13.6-24 16.9-28 R3 Turf - Front 28x8.50-15 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear 41x14.00-20 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 12-16.5 12.5/80-18 (4WD) R4 Industrial - Rear 17.5L-24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach faceplate LA1153: two-lever quick coupler Loader Model L360A LA1153 Loader Lift Height 112 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) 1,830 lb at 31.5 in. forward of pivot pin (L360A) Not Published Loader Breakout Force 3,114 lbf Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 4 additional years Not Published
